• Model NO.：STYE-2000G
• Accuracy Grade：1
• Load Way：Electronic Load
• Loading Method：Dynamic Load
• Display：Digital
• Control：Manual Control
• Weight：850
• Power Source：AC380V
• Oil Cylinder Position：Under
• Max. Testing Power：2000kn
• Measuring Range：0-2000kn
• Test Frame：Whole Casting
• Test Range：20kn-2000kn
• Reading Accuracy：1%
• Displlacement Accuracy：1%
• Noise：Less Than 40dB
• Working Voltage：AC220V
• Transport Package：Wooden Case
• Specification：950x400x1160mm
• Trademark：SHTG
• Origin：China
• HS Code：9031809090
• Production Capacity：100PCS,Month

Basic Info.

Model NO. STYE-2000G Accuracy Grade 1 Load Way Electronic Load Loading Method Dynamic Load Display Digital Control Manual Control Weight 850 Power Source AC380V Oil Cylinder Position Under Max. Testing Power 2000kn Measuring Range 0-2000kn Test Frame Whole Casting Test Range 20kn-2000kn Reading Accuracy 1% Displlacement Accuracy 1% Noise Less Than 40dB Working Voltage AC220V Transport Package Wooden Case Specification 950x400x1160mm Trademark SHTG Origin China HS Code 9031809090 Production Capacity 100PCS/Month

Product Description

STYE-2000 Digital Display Hydraulic Compression Testing Machine CTM

STANDARD: EN 12390-4 ASTM C39, AASHTO T22

Use:
STYE-2000 Digital Display Hydraulic Compression Testing Machine is designed to conduct compression and crushing strength tests on Containers, Concrete cubes,cylinders, hollow blocks and various other materials in accordance with International standard. The machine is electro-hydraulically operated. The Control Panel comprises of Hydraulic Power Pack, Digital Readout System, Operating Switches, Load Control Valves, Output Print-out of Test Data.

Feature:
Efficient hydraulic power packs
Economic machines ideal for site use Designed to meet the need for a simple, economic and reliable means of testing concrete.
The dimensions of the frame allow the testing of cylinders up to 320 mm long x 160 mm diameter, and cubes 200mm,150mm or 100 mm square, 50 mm/2 in. square mortar cubes, 40 x 40 x 160 mm mortar and any arbitrary size.
Digital readout is a microprocessor controlled instrument which is fitted as standard to all digital machines in the range.
Calibrated accuracy and repeatability is better than 1% over the upper 90% of the working range.

Specification:

Model	STYE-2000
Max. testing power	2000kN
Measuring range	0-2000kN
Test frame	whole casting
Test range	20KN-2000KN
Reading accuracy	±1%
Displacement accuracy	±1%
Noise	<40dB
Working voltage	AC220V±10%
