• Model NO.：PN-BSM600
• Transport Package：Wood Case, Free-Fumigation
• Specification：ISO standards
• Trademark：PNSHAR
• Origin：Hangzhou, Zhejiang
• HS Code：90248000
• Production Capacity：300sets,Year

Basic Info.

Model NO. PN-BSM600 Transport Package Wood Case, Free-Fumigation Specification ISO standards Trademark PNSHAR Origin Hangzhou, Zhejiang HS Code 90248000 Production Capacity 300sets/Year

Product Description

1. Instruction:
Mullen type bursting strength tester burst tester is a new type testing machine to test the bursting strength of corrugated boards, which is designed in accordance with related ISO standards and on the principle of modern mechanical design concept and design criterion of human-machine engineering. PN-BSM600 Bursting Strength Tester belongs to electromechanical product which is with novel design, convenience for use, excellent performance and elegant appearance. PN-BSM600 Bursting Strength Tester has abundant functions, such as, parameter testing, parametric transformation, parameter adjusting, parameter memory and parameter print. All are in accordance with related ISO standards. PN-BSM600 Bursting Strength Tester has data processing function which can directly output result of data statistics with convenient operation, easy regulation and stable performance.

2. Principle:
A test specimen is placed over a circular elastic diaphragm, it is rigidly clamped at the periphery but free to bulge with the diaphragm. Hydraulic fluid is pumped at a constant rate,  and bulged the diaphragm until the test piece ruptures. The bursting strength of the test piece is the maximum value of the applied hydraulic pressure.

3. Applications: Corrugated cardboard, Corrugated box.

4. Standards:  ISO 2759


NO.	SPECIFICATION	RESULT
1	Power:	AC220V+/-10% 2A 50Hz
2	Measuring Range:	300~5500kPa
3	Compression rate:	170+/-15ml/min
4	Resolution:	0.1kPa
5	Accuracy:	More than 99.5 %
6	Diaphragm size:	Bulge height: 2.5+/-0.2mm Bulge diameter: 27.8mm
7	Diaphragm resistance:	When the bulge height is 10mm, the pressure is 170~220kpa When the bulge height is 18mm, the pressure is 250~350kpa
8	Upper clamp:	31.5+/-0.05mm
9	Lower clamp:	31.5+/-0.05mm
10	Hydraulic transducer:	<6000kpa
11	Clamp pressure:	More than 690kpa
