• Model NO.：ZJA
• Filtration Accuracy：≤1-3um
• Breakdown Voltage：70-75kv
• Water Content：3-5ppm
• Transport Package：Standard Wooden Case
• Specification：120~2200KG
• Trademark：GOLD
• Origin：China
• Production Capacity：1000set,Month

Parameters

Unit

1.8KY

3KY

6KY

9KY

12KY

18KY

Flow Rate

L/H

1800

3000

6000

9000

12000

18000

Working Vacuity

Pa

≤80

≤80

≤80

≤80

≤80

≤80

Working Pressure

Mpa

≤0.5

≤0.5

≤0.5

≤0.5

≤0.5

≤0.5

Temperature Range

ºC

45-65

45-65

45-65

45-65

45-65

45-65

Power Supply

50Hz

380V

3 Phase

4-Wire

or as request

Total Power

KW

16

36

70

100

150

200

Inlet/Outlet Diameter

mm

20/20

25/25

32/32

40/40

50/50

65/65

Length

mm

1600

1800

2200

2500

2800

3450

Width

mm

1250

1450

1600

1950

2150

2600

Height

mm

2000

2200

2450

2700

3000

3000

Weight

Kg

500

700

1460

1800

2400

4000

Index of oil after purifying:

Breakdown Voltage

KV

70-75

Water Content

ppm

3~5

Gas Content

%

≤0.2

Filtering Accuracy

µm

1~3

Feature:

1. One pot has two-stage vacuum isolation space with different pressures to maintain oil circuit balance betweenthe two stages.
2. Vacuum pumps imported from Europe are at the leading level in the world, and high air pump speeds ensure ahigh working vacuum.
3. New technology for vacuum separation using special spinning discs and stainless steel machines with dewatering and air pumps
4. The use of new heating equipment can reduce heat generation and extend oil life.
5. The oil level control uses a photoelectric method, and the main components are imported from Switzerland.
6. Customers can choose equipment equipped with all or part of imported components.
7. It is equipped with a filter assembly imported from Italy.
8. All pumps must be hermetically sealed at our factory and must be noise-free and leak-free when  operating, extend oil life.

CHONGQING GOLD MECHANICAL & ELECTRICAL EQUIPMENT CO., LTD

Chongqing Gold Mechanical & Electrical Equipment Co.,Ltd.  mainly design and manufacture the oil purifier and electrical testing equipment for more than 10 years.

After several years' development, our products have become high intelligent and wide coverage. And our company has become one of the leading manufacturer of oil purifier and electrical testing equipment in China;

We have developed sales channels in many countries such as UAE, Saudi Arabia, Iran, Malaysia, Thailand, Pakistan, India, Germany, Belgium, USA, Mexico, Kenya, Nigeria, South Africa and other countries worldwide.

And we have gained strong advantage and high reputation in international market.

We have persisted on the business idea of "Integrity Basis and Quality First" for the stable and constant development. We are making effort to develop together with customers from both domestic and abroad on the basis of reciprocity. Client, quality and service are our supreme target!
