• Model NO.：PN-CT300F
• Power Supply：AC220V, 50,60Hz
• Capacity：0-3000n
• Certificate：Calibration Certificate, ISO Certificate
• Warranty：One Year
• Package Size：550*520*660mm
• Transport Package：Wood Case, Free-Fumigation Package
• Specification：SGS
• Trademark：PNSHAR
• Origin：Hangzhou, Zhejiang, China
• HS Code：90248000
• Production Capacity：300sets,Year

Basic Info.

Model NO. PN-CT300F Power Supply AC220V, 50/60Hz Capacity 0-3000n Certificate Calibration Certificate, ISO Certificate Warranty One Year Package Size 550*520*660mm Transport Package Wood Case, Free-Fumigation Package Specification SGS Trademark PNSHAR Origin Hangzhou, Zhejiang, China HS Code 90248000 Production Capacity 300sets/Year

Product Description

Laboratory testing equipment for Corrugated paperboard Ring Crush Tester with crush testing

1. Description:
Laboratory testing equipement for Corrugated paperboard Ring Crush Tester with crush testing is used for the test of Ring Crush Test (RCT), Edge Crush Test (ECT), Flat Crush Test (FCT), Pin Adhesion Test (PAT), Corrugating Medium Test (CMT) an Corrugated
Crush Test(CCT).

2. Applications:
Paper, Paperboard, Corrugated cardboard, Corrugated Package.

3. Standards: ISO 3035. ISO 3037. ISO 7263.

4. Features:
1) High speed return after finishing test
2) Imported step motor with servo control adopted
3) The test result can be measured, statistical and printed automatically and the data can be saved.
4) Blue color LCD display, which can be display the crush time and loading force real time, PN-CT300B can display crush graph real time.
5) New PC software able to manage and analyse the data and can communicate with PC. (Only for PN-CT300B-PC type).
6) Built-in thermal printer

5.Specification:


ITEM	SPECIFICATION
Power:	AC100~240V, 2A,50Hz/ 60Hz.
Accuracy:	±1%
Indication varation:	<1%
Resolution:	0.1N
Measuring range:	(5~5000)N
Parallelism:	≤ 0.034mm
Stroke:	(2~70)mm
Test speed:	(12.5 ± 2.5) mm/min(1~30mm/min can be set)
Return speed:	(5~30) mm/min
Display:	7" touch screen display and English menu
Printer:	Thermal printing, high speed and low noise
Data output:	RS232(Standard) / USB(Optional)
Work environment:	Temp.(20±10 )°C relative humidity < 85%
Dimension:	(375×345×505 ) mm(L×W×H)
Net Weight:	About 38.6 kg
