• Model NO.：H1820
• HS Code：90248000
• Production Capacity：1000 Sets,Month

Basic Info.

Model NO. H1820 HS Code 90248000 Production Capacity 1000 Sets/Month

Product Description

SPECIFIC GRAVITY (RICE TEST) EQUIPMENT
STANDARD: AASHTO T209, AASHTO T283
Large-Capacity Vacuum Pycnometer Set

    Large-capacity unit, 10L (2.64 gal.), 6000g (13.2 lbs.) sample weight, with maximum aggregate size of 50mm (2in.). Set features domed transparent cover for easy observation of sample testing, perforated plastic shelf, which some States require; water inlet valve and 1/4" ID hose, vacuum hose and aspirator with 3/8" NPT fitting.
Flange OD is 10-3/4" (273mm); maximum clearance above plate is 7-3/4" (197mm).
Dimensions: 9-7/16" ID x 12-1/8" (240 ID x 311mm).

Packing list
Vibrating table
Digital absolute vacuum gauge
Vacuum container
Vacuum pump

    Heavy-duty vibrating table keeps sample material loose for more reliable test results. Strong, rugged-duty vibrator and sturdy base have integral, heavy-duty on/off switches.
    Exclusive quick-release cam/lock fasteners allow quick placement and removal of canister. Shipping wt. 12lbs
(5.4kg).
