Rheology Laboratory Device Mdr Moving Die Rheometer for Rubbers
Qingdao Evertech Industry Co., Ltd.- Max Diameter of Workpiece:<500mm
- Mass Scope of Workpiece:<900kg
- Type:Material Testing Machine
- Maxcapacity:<1000KN
- Accuracy Grade:0.5
- Load Way:Mechanical Load
Base Info
- Model NO.:BN-4000B
- Loading Method:Static Load
- Display:Digital
- Control:Computer Control
- Weight:100-500Kg
- Power Source:AC220V
- Oil Cylinder Position:Under
- Load Cell:United States High-Precision Se
- Bearing:Japan NSK High-Precision Bearings
- Control Mode:Computer Temperature Control, Alpha Technology Acc
- Fixtures:Sino-Foreign Joint Venture Germ
- Report Content:Ml, Mh, Ts1, Ts2, T10, T30, T50, T70, T90, Vulcani
- Standard:ASTM D5289-95, ISO 6502
- Power Supply:220V 50Hz
- Certificate:Ce ISO
- Warranty:Yes, 12 Months
- Transport Package:Inner Packaging with PE Protective Film
- Specification:Electronic
- Trademark:Evertech
- Origin:Shandong, China (Mainland)
- HS Code:84778000
- Production Capacity:50 Set,Sets Per Month
Description
Model
China Supplier Rubber Plastic Moving Die Rheometer MDR
Temperature tester
Room temperature to 200°C
Temperature accuracy
≤ ±0.3°C
Temperature resolution
0.1°C
Torque range
0-5N.M,0-10N.M,0-20N.M
Torque resolution:
0.001NM
Motor rotating speed
100 times / min
Rotor range
Adopt 4 setting: 25, 50, 100, 200lbs per inch
Die cavity frequency
1.7Hz
Sway angle
±0.5°, ±1°, ±3°
Air compression
0.5Mpa--0.65MPa
Ambient temperature
0-35°C
Test result
Printing:date,time,temperature,vulcanization curve,
temperature curve,ML,MH,ts1,ts2,t10,t50,Vc1,Vc2.
Dimension
131*56*62cm
Power
Single phase, 220V±10%, 50Hz
Display
Windows 7 + software
Weight
250kg
About Evertech
Related Products
Our Service
Pre-Sales Service
* Make the best offer base on customer's needs
* Confirm delivery time, shipping mode for customer.
* Sign the contract and swift the amount.
* Support trade assurance order to protect payment to delivery.
After-Sales Service
* Help customer put the machine into use, for installation and operation.
* Timely technical support for the questions.
* One year warranty time, timely spares for replace.
* Lifetime after-sales service and free software upgrade.
Packing & Delivery
