• Model NO.：GD-2265
• Lubricating Grease Test：ASTM D2265 Dropping Point Device and Dropping Poin
• Temperature Control Point：121c, 232c, 288c, 316c, 343c
• Temperature Control Accuracy：1c
• Test Result Capacity：Automatic Saving 256 Test Results
• OEM Service：Available
• Warranty：1 Year
• Transport Package：Wooden Case or Plywood
• Origin：China
• HS Code：9031809090
• Production Capacity：200PCS,Month

Basic Info.

Model NO. GD-2265 Lubricating Grease Test ASTM D2265 Dropping Point Device and Dropping Poin Temperature Control Point 121c, 232c, 288c, 316c, 343c Temperature Control Accuracy 1c Test Result Capacity Automatic Saving 256 Test Results OEM Service Available Warranty 1 Year Transport Package Wooden Case or Plywood Origin China HS Code 9031809090 Production Capacity 200PCS/Month

Product Description

ASTM D2265 Automatic Wide Temperature Range Dropping Point Tester for Lubricating Greases






Introduction:

The Automatic Wide Temperature Range Dropping Point Tester for Lubricating Greases is designed and manufactured strictly according to National Standard GB/T 3498 and ASTM D2265 Standard Test Method for Dropping Point of Lubricating Grease Over Wide Temperature Range.
The Automatic Wide Temperature Range Dropping Point Tester for Lubricating Greases is applicable to the automatic determination of lubricating grease dropping point when its first drop reaches the bottom of the test tube.


Features:

1. 7 Inch LCD touch screen HMI with beautiful outlook design. Full English operating system is stalled. Instruction interfaces are clearly displayed to provide guide for test completion.
2. High-performance microprocessor as core of MCU, fully automatic control throughout the whole test procedures.
3. Highly integrated bench top instrument with multiple functions.
4. Specially designed photoelectric sensor for dropping point detection with high sensitivity and fast response.
5. It features double sample holes, single test or dual tests can be performed. Fast temperature rising rate with  ±1ºC metal bath temperature accuracy. It features fault self-diagnosis system and reminder functions.
6. Automatic test results and experiments number saving functions with auto test results printing.
7. User-friendly and easy -to-operate,  average test time is less than 2 mins.


Specifications:

1. Operating voltage: AC220V, 50Hz
2. Operating power: 1200W
3. Metal bath type: Aluminum
4. Sample channels: 2
5. Temperature sensor: A class PT100*2
6. Test method: auto photoelectric sensor
7. Temperature control range: R.T. ~ 400ºC
8. Temperature control point: 121ºC,232ºC,288ºC,316ºC,343ºC
9. Temperature control accuracy: ±1ºC
10. Test result capacity: automatic saving 256 test results
11. Printing method: auto thermal printer
