• Model NO.：SXIJJ
• Loading Method：Dynamic Load
• Display：LCD
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC 110V,220V at Customized
• Oil Cylinder Position：Under
• Voltage Range：AC0~80kv, 0~100kv
• Oil Cups：3
• Stirring Time：0-1 Minute 9 Seconds
• Limitation Current：5mA
• Transport Package：Plywood Case
• Specification：ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9030899090
• Production Capacity：1000 Units

Basic Info.

Model NO. SXIJJ Loading Method Dynamic Load Display LCD Control Computer Control Weight 0-100Kg Power Source AC 110V/220V at Customized Oil Cylinder Position Under Voltage Range AC0~80kv, 0~100kv Oil Cups 3 Stirring Time 0-1 Minute 9 Seconds Limitation Current 5mA Transport Package Plywood Case Specification ISO9001 SGS Trademark Sansion Origin Wuhan, China HS Code 9030899090 Production Capacity 1000 Units

Product Description

Transformer Oil Breakdown Meter

General Information:

Keywords: Oil Dielectric Strength Tester
Oil Breakdown Tester
Transformer Oil Dielectric Strength Tester

SXOT-II conforms to international standard IEC-156 and national standard GB507-86, can be used for power frequency dielectric break down test on the transformer oil, capacitor oil, electric device, insulation tool, electric manufacturer and etc. It's widely used in the fields of power system, petroleum, chemical industry, railway station, power station, electric manufacturer and etc.

Features:
√  Self detecting function. The regulator could return to zero start automatically.
√  Controlled by micro computer, easy to operate.
√  Build-in printer.
√  Automatic magnetic bar stir, to eliminate uneven and bubble of oil.
√  The user could select the test times, static stirring time, sound/light alarm continuously printing or stop printing.

The equipment to match the standard IEC 156, and the instrument is fully automatic type.

Specification:
Power supply: AC 200V-240V ,50HZ ±5%
Test voltage: : AC 0~100KV
Limitation current: 5mA
Test precision: 1%
Voltage boosting rate:  2KV/s±10%
Presetting: 1-9 times
Stirring time: 0-1 minute 9 seconds
Static time: 0-10 minutes 39 seconds
Environmental temperature: 0-35ºC
Relative humidity: ≤75%RH
Power: 300VA
Electrodes Gap Size: 2.5mm
Volume: 420×320×325mmWeight: 28KG

Warranty: One year quality guarantee after shipment.

More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
