• Model NO.：GD-261
• Load Way：Electronic Load
• Loading Method：Dynamic Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Top
• Power Supply：AC (220±10%)V, 50Hz
• Heating Device：The Heating Power Is Continuously Adjustable From
• Heating Rate：(1~12)ºC,Min; Controllable and Adjustable
• Stirring Rate：Procedure a: (90~120)Rpm
• Ambient Temperature：≤ 35ºC
• Relative Humidity：≤ 85%
• Maximum Power Consumption：650W
• Transport Package：Wooden Case
• Specification：1320mm*750mm*1400mm
• Trademark：GOLD
• Origin：China
• Production Capacity：10000 Sets, Month

1. Power supply:AC( 220±10% )V, 50Hz.2. Heating device:.

(1) The furnace is a silicon carbide material. Power is 600W
(2) The heating power is adjustable from 0 W to 600W.

3. Heating rate:Procedure A:  ( 5~6)ºC/min, Procedure B:(1~1.5)ºC/min.  Automatically controlled4. Stirring device:

(1) Driving mode: flexible shaft
(2) Shaft size: 8mm×40mm
(3)Stirring motor: BYGH101 stepping motor

5. Stirring rate:

Procedure A: (90~120)RPM,

Procedure B: (250±10)RPM

6. Igniting device:(1) Igniting source: gas(or other civilian fuels,the same below)
(2) Electric ignition. Gas flame diameter:3.2mm~4.8mm7. Temperature testing probe:RTD, PT1008. Ambient temperature:≤ 35ºC9. Relative humidity:≤ 85%10.Maximum power consumption:650W

Packing&Delivery






Company Profile

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd. which is mainly design and manufacture the petroleum testing instrument, asphalt testing equipment and related lab equipment.After more than 20 years' development, our products have become high intelligent and wide coverage. And our company has become one of the leading manufacturer of petroleum testing instrument and asphalt testing instrument. We have developed sales channels in many countries such as UAE, Saudi Arabia, Malaysia, Thailand, Pakistan, India, Germany, Belgium, USA, Mexico, Kenya, Nigeria, South Africa and other countries worldwide.And we have gained strong advantage and high reputation in international market.
