in-Situ Direct Shear Test Apparatus of Rock and Soil

Zhuozhou Tianpeng Imp. & Exp. Trade Co., Ltd.
  • Transport Package：Wooden Cases
  • Trademark：C-Tech
  • Origin：China Mainland

Base Info

  • Model NO.：XCJY
  • HS Code：90248000
  • Production Capacity：100 Sets,Month

Description

Dimension of shear box

500mm×500mm×220mm;                                700mm×700mm×280m

JackNormal direction 300KN stroke 200mm;
Tangential 500KN stroke 200mmPressure sensorResistance strain load cell, bridge resistance 350Ω
Measuring range: 0~300kN ~500kN
Output sensitivity: 2mV/V
Accuracy: comprehensive error≤0.5%FSDial gaugeMeasuring range: 0~30mm
Measuring range: 0~50mmReaction deviceFrame type
Main beam span 5m
Supporting beams 4pcs
Single blade ground anchor Ø300mm
