• Model NO.：GDZRC-10H
• Production Capacity：10000PCS,Year

Basic Info.

Model NO. GDZRC-10H Production Capacity 10000PCS/Year

Product Description

GDZRC-10H Handheld Transformer DC Winding Resistance Tester




GDZRC-10H Hand-held Transformer DC Winding Resistance Tester is not only suitable for the measurement of inductive test object such as transformer, CT/PT and reactor, but also for the measurement of resistive test object such as copper bar, wire and switch contact.
As a newly-designed product, it has features of small size, fast test speed and high accuracy.


Features

1. Lithium battery power supply and 220V AC power supply. charge once, continuous testing hundreds of transformers, simple operation, more convenient.
2. Output 6 steps of current, Max. output current 10A, Max. output voltage 25V, and current step can be automatically selected. Wide range of 500uΩ~50 kΩ.
3. With the resistance temperature conversion function, and wireless temperature measurement module can be selected, real-time measurement of field sample temperature, to ensure the accuracy of resistance conversion value.
4. With a variety of protection functions such as counter electromotive force protection, wire breakage protection, powed-off protection, overheating alarm, etc.
5. 5.6-inch industrial grade high brightness color LCD screen, the display is still clearly visible in strong sunlight.
6. Equipped with external printer for printing.
7. It has local storage and flash storage.

Specifications
DC Winding resistance

Current step	Measurement range
1mA	500Ω~50kΩ
10mA	50Ω~2kΩ
100mA	10Ω~200Ω
1A	100mΩ~20Ω
5A	10mΩ~1Ω
10A	500uΩ~200mΩ



1. Accuracy: ±(reading*0.2%+2 digits)
2. Min. resolution: 0.1uΩ
3. Weight: 1.6kg (without test lines)
4. Size: 246*156*62mm

Use conditions

1. Power supply: 100~240VAC, 50/60Hz

       Lithium battery:

1. Charging voltage: 16.8V
2. Charging current: ≤3A
3. Charging time: about 4 hours
4. Working time: more than 8 hours
5. Working temperature: -10~50ºC
6. Relative humidity: ≤90%, no condensing
