• Model NO.：HD-J214
• Display：Digital
• Control：Computer Control
• Weight：500-1000Kg
• Power Source：AC220V
• Usage：Baby Stroller Handle Durability Tester
• Design Criteria：En 1888
• Adjustable Distan：300mm
• The Fixed Method of The Handle：Mobile or Replaceable
• Automatic Timer：LED, 1~9999 Times
• Dimension of The Machine：(L*W*H) 1650*1100*1900mm
• Power：AC220V, 50Hz
• Testing Space：Can Be Customized
• Model：HD-J214
• Display Method：Digital
• Transport Package：Strong Plywood Case
• Specification：EN 1888
• Trademark：Haida
• Origin：Dongguan, China
• HS Code：9024109000
• Production Capacity：150 Sets Per Month

Basic Info.

Model NO. HD-J214 Display Digital Control Computer Control Weight 500-1000Kg Power Source AC220V Usage Baby Stroller Handle Durability Tester Design Criteria En 1888 Adjustable Distan 300mm The Fixed Method of The Handle Mobile or Replaceable Automatic Timer LED, 1~9999 Times Dimension of The Machine (L*W*H) 1650*1100*1900mm Power AC220V/ 50Hz Testing Space Can Be Customized Model HD-J214 Display Method Digital Transport Package Strong Plywood Case Specification EN 1888 Trademark Haida Origin Dongguan, China HS Code 9024109000 Production Capacity 150 Sets Per Month

Product Description

Hand strollers lift down durable test machine
 Brief  Introduction:
 This machine is to test the upholding and pushing durability property of the baby stroller according to ASTM Standards. The test method is: place the baby model in the stroller, leave the trailing wheel 150mm high from the ground when lifting the stroller; leave the front wheel 150mm high from the ground when pushing it, repeat this method continuously for 3000 times at the speed of 15±1 per minute, and check whether the stroller is damaged. The machine will stop automatically when it up to its set-up times, so there is no need to watch it.



Main Parameters:


Power of upholding and pushing	driven by pneumatic cylinder, can lift and push 50kg.
The fixed method of the handle	mobile or replaceable
Adjustable distance from the handle joint	300mm
Function of upholding and pushing	leave the trailing wheel 150mm high from the ground when upholding, leave the front wheel 150mm high from the ground when pushing.
Automatic timer	LED, 1~9999 times
Testing space	can be customized
Dimension of the machine	(L×W×H) 1650x1100x1900mm
Weight	850kg
Power	1∮, AC220V/ 50Hz

The usage:
1.Position the vehicle on a horizontal surface without the parking device applied.
2.Place the test mass as for the stability test. If the vehicle is designed for more than one child use any
number of appropriate test masses, up to one in each place intended to be occupied by a child.
3.Alternately raise and lower the handle(s) by applying a vertical force to the handle so that the rear wheels and front wheels in turn are raised (120 ± 10) mm, measured at the start of the test from the floor and then lowered in a controlled manner without pause (see Figure A).
4.Carry out the test for a total of 10 000 cycles at a frequency of (15 ± 2) cycles/min.


Introduction:

HAIDA INTERNATIONAL is a professional manufacturer of various kinds of testing equipments over 24 years. HAIDA products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and applicable to all scientific research units, quality inspection institutions and academic fields.

Company :

After-service:

If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-con.
