Hanging Type Heating Impact Test Chamber Thermal Shock Chambers Auto Spare Parts Test

Guangdong Yuanyao Test Equipment Co., Ltd.
  • Certification：CE, TUV, ISO, SGS
  • Warranty：1 Year
  • Inner Size：500*350*500mm
  • External Size：1600*2050*2220mm
  • Volume：87 Liters
  • Preheat Temp. Range：+200 Degrees

Base Info

  • Model NO.：YTST-087
  • Precool Temp. Range：-60degrees or -75degrees
  • Test Temp. Range：+60degrees-- +150degrees
  • Temp. Fluctuation：+,- 2 Degree
  • Temp. Recovery Time：Within 5 Mins
  • Interior Chamber Material：SUS#304 Stainless Steel Plate
  • Exterior Chamber Material：Stainless Steel Plate + Powder Coated
  • Transport Package：Strong Wood Carton
  • Specification：SGS, TUV Certification
  • Trademark：Yuanyao
  • Origin：China
  • HS Code：9032100000
  • Production Capacity：10 Sets,Month

Description

SpecificationModelYTST-056YTST-087YTST-126Internal Dim.W×H×D(mm)400×350×440500×350×500600×350×600External Dim.W×H×D(mm)1500×2050×21201600×2050×22201700×2050×2320Pre-heat Limt +200ºCPre-cool Limit  -60ºC    -75ºCTest Temp.Range  +60ºC--  +150ºC; -10ºC--  -50ºC; -10ºC--  -65ºCFerformanceTemperature Constancy  ±2ºCTemp.Recover TimeWithin 5 minsHeat-up TimeºC150150150min303030Pull-down TimeºC  -50       -65  -50       -65  -50       -65min  90       90  90       90  90       90MaterialExteriorStainless steel plate + Powder CoatedInteriorSUS # 304 stainless steel piate (Hairline Finish)InsulationPU & FiberglasswoolSystemsCirulationsirocofanHeatingstripped wire heaterRefrigerationCompressor+Evaporator fins+water-cooling condenserController1POther ComponentsExper iment separation shelves(freely adjustable 2pcs)Sevey DevicesNo fuse breaker,Motor overload protection High/low pressure shut off device,Open door operation prevention switch, Flow switch protector cooling water.Power Source[K.W.]AC 1Ψ 220V;3Ψ 380V 60/50Hz90        90  90        90  90        90
Except Hanging type heating impact test incubator, we can supply:

Precision Oven Tester, Triple Type Temp. & Humi. Chamber, Temp. &Humi. Control Host, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Walk-in environmental Test Room, Temp. Humi. &Vibration Conbined Test Chamber, Aging Oven Tester, Rain/Spray Test Chamber, Burn-in test equipment, Dust Tester, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester and so on.
Hanging Type Heating Impact Test Chamber Thermal Shock Chambers Auto Spare Parts Test

CE, SGS, TUV, ISO 9001:2015 certified manufacturer.
Hanging Type Heating Impact Test Chamber Thermal Shock Chambers Auto Spare Parts Test

Welcome to enquire and purchase!
