Transformer Winding Resistance Tester automatic transformer DC resistance tester GDZRC-50U

HV Hipot Electric Co., Ltd.
  • Type：Universal Testing Machine
  • Accuracy Grade：0.2
  • Load Way：Electronic Load
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control

Base Info

  • Model NO.：GDZRC-50U
  • Weight：17kg
  • Power Source：AC220V
  • Oil Cylinder Position：no
  • Output current：<5mA, 2.5A, 5A, 10A, 20A, 50A
  • Min. resolution：0.1μΩ
  • Transport Package：Standard Export Wooden Box
  • Specification：325mm*240mm*275mm
  • Trademark：HV Hipot
  • Origin：China(Mainland)
  • HS Code：9031809090
  • Production Capacity：5000sets,Year

Description

Output current

<5mA, 2.5A, 5A, 10A, 20A, 50A

Min. resolution

0.1μΩ

Measurement range

±(0.2%+2digits)

Operation temperature

0~40ºC

Humidity

<90%RH (no condensing)

Size

17kg (without test wire)

test wire box: 3kg
