• Model NO.：HTPV-02A
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Material：Stainless Steel
• Product Name：PV Module Backplane Anti-Scratch Tester
• Certificate：ISO and SGS
• Standard：IEC 61215
• Delivery：30 Work Days
• Packages：Wooden Case
• Transport Package：Wooden Case
• Specification：IEC61730 and UL1703
• Trademark：HOTOTECH
• Origin：Dongguan
• HS Code：9013809000
• Production Capacity：50 Sets Per Month

Basic Info.

Model NO. HTPV-02A Control Manual Control Weight 0-100Kg Power Source AC220V Material Stainless Steel Product Name PV Module Backplane Anti-Scratch Tester Certificate ISO and SGS Standard IEC 61215 Delivery 30 Work Days Packages Wooden Case Transport Package Wooden Case Specification IEC61730 and UL1703 Trademark HOTOTECH Origin Dongguan HS Code 9013809000 Production Capacity 50 Sets Per Month

Product Description

PV Module Backplane Anti-Scratch Tester

PV module Backplane Anti-Scratch Tester Standard
According to IEC61730-2 and UL1703

PV module Backplane Anti-Scratch tester Purpose
It's to determine whether any front and rear surfaces of the module of polymeric materials are capable of withstanding routine handing during installation and maintenance without exposing personnel to danger of electric shock


PV module Backplane Anti-Scratch tester Parameter
1.Aluminum alloy material operate talbe, size approx 1.4m×0.65m
2.Operate talbe include tracking pulley wheel, tracking head slide and moving convenience
3.Test fixture
3.1 Adopt carbon steel blade
3.2 Promise 0.64mm±0.05mm thick requirement , and satisfy 0.115±0.025mm blade radius requirement
3.3 Space and angle can adjust
3.4 Included the weight box on thw saw bar
3.5 According to IEC61730-2 standard requirement adjust weights , promise the test point with gravity 8.9N±0.5N
4.Adopt motor constant speed tracking, speed continue and adjust, tracking directing can adjust
5.Promise the test fixture to 150±30mm/s speed pull the modules
