• Model NO.：XQ-2B
• Control：Manual Control
• Weight：500-1000Kg
• Power Source：AC220V
• Oil Cylinder Position：Top
• Transport Package：Plywood
• Specification：2CBM
• Trademark：HENSGRAND
• Origin：China

Basic Info.

Model NO. XQ-2B Control Manual Control Weight 500-1000Kg Power Source AC220V Oil Cylinder Position Top Transport Package Plywood Specification 2CBM Trademark HENSGRAND Origin China

Product Description

  XQ-2B metallographic specimen inlaying machine


 TEL: 8615098778967
 Application:Model XQ-2B Metallographic specimen mounting presses suitable for the thermo-hardening plastic pressing of the small metallographic specimen which is not idiomorphic or hard to take.After forming, it will be very easy to process the grinding, polishing of the specimen and it is also convenient to process measuring of metallographic structure under metallographic microscope.

The machine may work stablely under the following working condition:
The temperature of surrounding medium can not be less than 10 ºC and more than 40ºCThe relative humidity of air should be no more than 85% (20 ºC)The voltage fluctuation should be no more than 15%There should be no obvious vibration source aroundThere should be no current conducting dust, explosive and corrosive air
Main specifications:

Model	XQ-2B
Mould diameter	22mm / 30mm / 45mm
Heater specifications	≤ 800W AC 220V 50Hz
Temperature adjusting range	0-400 ºC
power supply	single phase, 220V, 50Hz
Net weight	35Kg
Dimension	260×360×450mm
