• Model NO.：GDZG-300-60,10
• Weight：0-100Kg
• Power Source：AC220V
• Output voltage：60kV customized
• Output current：10mA customized
• Transport Package：Standard Export Wooden Box
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan, China
• HS Code：9030899090
• Production Capacity：5000set,Year

Basic Info.

Model NO. GDZG-300-60/10 Weight 0-100Kg Power Source AC220V Output voltage 60kV customized Output current 10mA customized Transport Package Standard Export Wooden Box Specification ISO, SGS Trademark HV Hipot Origin Wuhan, China HS Code 9030899090 Production Capacity 5000set/Year

Product Description

General Information

GDZG-300 series of DC high voltage tester is testing DC high voltage for zinc oxide lighting arrester, magnetic blowing arrester, power cables, generators, transformers, switches and other equipments, which is suitable for electric power branch, power department of factories, scientific research units, railway, chemical industry, power plants.


Features


1. Use high frequency voltage multiplier circuit, PWM pulse width modulation technology and high power IGBT device .
2. With large voltage feedback, the output voltage stability is high and the ripple coefficient is ≤ 1%.
3. Smooth voltage regulation of full range, fine voltage regulation, accuracy is ≤ 0.5%, stability is ≤ 1%, voltage and current error is 1% (reading (±0.2kV), current error ±1 digital.
4. The boost potentiometer starts from zero.
5. With 75% UDC1mA function button, convenient for zinc oxide arrester test, accuracy is 1% reading±1%.
6. Over-voltage protection using the dial code setting, very clear, the error is ±1%.
7. Double pressure is made of new materials, which is light and sturdy. The exterior is coated with special insulating materials, which have good electrical performance and strong moisture resistance.
8. Folding feet, large diameter area, good stability.
9. Integrated design and high-voltage mopping cable are taken out to facilitate on-site testing.
10. The product meets the technical requirements of DL/T848.1-2004, and has been tested by the electrical equipment quality testing and testing center of the Ministry of Power, and strictly enforces the enterprise standard.

Specifications(60kV/10mA)

Output voltage	60kV customized
Output current	10mA  customized
Output power consumption	60W
Box weight	7kg
HV Booster weight	3kg
HV Booster height	450mm
Power supply	AC220V±10%, 50Hz
Voltmeter accuracy	±1.0% of the reading±2digit, max resolution 0.1%kV
Ammeter accuracy	±1.0% of the reading±2 digit, max resolution 0.1%uA
Ripple coefficient	≤1%
Voltage stability	Random fluctuation, ≤1% (when voltage change ±10% )
Overload capability	No-load voltage can exceed 10% of rated voltage for ten minutes The maximum charging current is 1.5 times the rated current
Working mode	Intermittent use Max. 30 minutes for one time
Operation temperature	-10ºC~40ºC
Relative humidity	≤85%(no condensate), when temperature is 25ºC
Altitude	<1500m
