• Model NO.：GD-17144
• Temperature of Coke Chamber：500c
• Temperature Control Accuracy：+-2c
• Heating Power：1500W
• Ambient Temperature：5~35c
• Warranty：1 Year
• Transport Package：Wooden Case or Plywood
• Origin：Chongqing of China
• HS Code：9031809090
• Production Capacity：100 Sets , Month

Basic Info.

Model NO. GD-17144 Temperature of Coke Chamber 500c Temperature Control Accuracy +-2c Heating Power 1500W Ambient Temperature 5~35c Warranty 1 Year Transport Package Wooden Case or Plywood Origin Chongqing of China HS Code 9031809090 Production Capacity 100 Sets / Month

Product Description

MCRT Micro Carbon Residue Tester for Diesel Fuels by ASTM D4530 Micro Method



MCRT Introduction:

The Automatic Micro Carbon Residue Tester is designed and made as per GB/T17144-1997 Standard Test Method for Carbon Residue of Petroleum Products-Micromethod.
The Micro Carbon Residue Tester is suitable to determine the the amount of carbon residue of petroleum products.


CHARACTERISTICS:
 1. This Micro Carbon Residue Tester adopts all-in-one structure. It consists of two parts: electrical control chamber and high temperature heating furnace. The design is simple and reasonable.
2. It adopts single chip machine system. The instrument controls the whole procedures automatically according to program preset.3. The screen adopts all English interface. Operator can do determination by prompts on the screen even no need to read the operation manual. Easy to operate.4. It controls the flow rate of nitrogen, temperature heating rate and preset temperature automatically. Easy to adjust the flow rate. The heating rate is accurate and temperature control is stable.5. It collects test data and calculates results automatically. It can print and save the data according to customer's requirements.6. The measurement range of this instrument is 0.10%(m/m)~30.0%(m/m). The test result is equivalent to Conradson method if the carbon residue is higher than 0.10%(m/m).7. The Micro Carbon Residue Tester can also be used to determine the petroleum products composed of distillate oils which carbon residue is lower than 0.10%(m/m). But the specimen shall be sampling to 10%(V/V)distillation residue according to GB/T6536 firstly.8. It equips a electric balance to achieve the automation of sample weighing and data input.

SPECIFICATIONS:

1. Power supply:   AC(220±10%)V, 50Hz
2. Power consumption:  ≤1600W
3. Temperature of coke chamber:   500ºC
4. Temperature control accuracy:   ±2ºC
5. Heating power:   1500W
6. Ambient temperature:   5ºC~35ºC
7. Relative humidity:   ≤85%
8. Dimension:  520mm*360mm*525mm


PICTURES:
