• Model NO.：Yg368

Basic Info.

Model NO. Yg368

Product Description



YG368 Full-automatic Filament Crimp Contraction and Shrinkage Tester



Technical index:

1. Measured data: 30 Magzines

2. Sample length: 1000mm

3. Accuracy:0.04

4. Load: 2.5 - 5000cN (set at random)     accuracy: 0.2cN

5.Data output: displayable and printable

Standards:

GB/T6505, GB/T6506, etc.





Heating Cabinet for Crimp Contraction and Shrinkage Test

Application:

To cooperate with  filament crimp contraction and shrinkage tester  for measur ing  the  textured  sample  yarns  (polyester/ nylon / polypropylene).

Technical index:

1. Temperature range: room temperature - 300ºC

2.  Timing range: 1 second - 99 hours

3. Shelf dimensions: 415×460mm

4. Pressure: 0.4 - 0.8 Mpa

5. Inner dimensions L660×W570×H930mm

6. External dimensions L1030×W810×H1340mm

7. Power source: AC380V, 4.5kW



* The above information can be subject to changes by Alpha Machinery.



A full-automatic filament crimp contraction and shrinkage tester consists of a host, a heating vabinet, a boiling water pot, a test frame, a computer and a printer.



Full-automatic Filament Crimp Contraction and Shrinkage Tester

Application:

To  test  the contraction and shrinkage  for  textured yarns (polyester / nylon / polypropylene). Main measuring values are crimp contraction(CC%), crimp modulus(CM%), crimp  stability(CS%), boiling water shrinkage(BS%) and average  value(AVE),  standard deviation(SD),  variation coefficient value(CV) for all the items.
Company info:


TITA is a professional chemical fiber engineering company focusing on scientific research, technology innovation, chemical fiber yarn machinery manufacturing and contracting, we are specialized in improving the production processes of civil and industrial filaments of polyester, nylon, polypropylene, etc, civil staple, bi-component composite micro yarns in shapes of fragment, sea-island, sheath-core and side-by-side, and spun non-woven, as well as in developing new products and software, equipment design and manufacturing building planning and turn-key projects, etc.

We are committed to providing customers with our best quality machinery and services, and constantly to innovating and improving them to meet the increasing requirements and trends in the future, also we seek worldwide cooperation in hope making more outstanding success in the filed of chemical fiber machinery.

Major business:

1) Engineering design and turn-key project for POY and FDY by PET, PA6, PP, etc.

2) Spinning machines for industrial yarn, bi-component composite yarn and melt spandex yarn

3) Mother yarn splitting, Monofilament machines

4) BCF machine

5) Compact pilot spinning machine

6) Conversion for existing lines, modification for winders and spare parts supply, etc.
