• Model NO.：GD-323
• Transport Package：Wooden Case or Plywood
• Trademark：GOLD
• Origin：China
• HS Code：9031809090
• Production Capacity：100PCS,Month

Basic Info.

Model NO. GD-323 Transport Package Wooden Case or Plywood Trademark GOLD Origin China HS Code 9031809090 Production Capacity 100PCS/Month

Product Description

GD-8017 ASTM D323 RVP Reid Vapor Pressure Tester for Fuels



Introduction:

The Reid Vapor Pressure Bath is made and designed as per national standard of People's Republic of China GB/T 8017 Petroleum Products- Determination of vapor pressure- Reid method.
The RVP Reid Vapor Pressure Tester is used to test make determination for vapor pressure of gasoline, volatile crude oil and other volatile petroleum products.


Features:

1. Floor type structure. Stainless steel working table. It is good looking and easy to operate. Accessories are complete.
2. Digital temperature controller. The temperature in water bath is uniform. Temperature control accuracy is high. It can meet the requirements of test.
3. Two precise pressure meters to detect the gas pressure inside the bomb.
4. Two sets of vapor pressure bombs. It can do synchronous tests.


Specifications:

1. Power supply:   AC(220±10%)V, 50Hz
2. Heating power of bath:  1600W
3. Temperature control range of bath:  (Room temp.~90)ºC
4. Temperature control accuracy of bath: ±0.1ºC
5. Accuracy of pressure meter:  ±0.4%
6. Ambient temperature: (-10~35)ºC
7. Relative humidity: ≤85%
8. Maximum power consumption:  1700W
9. Dimension:    350mm*340mm*750mm
