48V 100A Voltage Monitoring System Battery Discharge Tester
HV Hipot Electric Co., Ltd.- Type：Universal Testing Machine
- Load Way：Mechanical Load
- Loading Method：Dynamic Load
- Display：Digital
- Control：Manual Control
- Weight：0-100Kg
Base Info
- Model NO.：GDBD-48V-100A
- Power Source：Single phase 3 wire 220V AC (-20%~+30%), 45~65Hz
- Oil Cylinder Position：no
- Applicable battery：DC 48V
- Output voltage：DC 38-60V
- Output current：0-100A
- PC communication：RS485 interface
- Data storage capacity：2G bit Flash
- Heat transfer：Forced air cooling
- Temperature：Working: 5~50ºC, storage: -40~70ºC
- Humidity：Relative humidity: 0~90%(40±2ºC)
- Altitude：Rated altitude 4000m
- Noise：<60dB
- Voltage：Single phase 3 wire 220V AC (-20%~+30%), 45~65Hz
- Safety：Meet EN610950
- AC input：Public socket for 1~1.5mm2 cable
- DC output：Tester 25mm2 cable quick connector
- Dimension & weight：415*180*310mm, 9kg
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HVHIPOT
- Origin：Wuhan China
- Production Capacity：2000PCS,Year
Description
Wiring
AC input
Public socket for 1~1.5mm2 cable
DC output
Tester 25mm2 cable quick connector (red positive black negative)
Dimension & weight
415*180*310mm, 9kg
