Transformer Insulating Oil Breakdown Voltage Bdv Tester 80kv Oil Dielectric Strength Test Machine
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- Product Name：Transformer Oil Bdv Tester
- Test Standards：IEC156, Is6792, BS5874, ASTM D1816 , ASTM D877
- Application：Test Breakdown Voltage Value of Transformer Oil
- Output Voltage：AC 0V~80kv (100kv for Choice)
- Rate of Voltage Rise：0.5kv,S, 2kv,S, 3kv,S, 5kv,S± 5%
- Display 1：LCD Touch Screen
Base Info
- Model NO.：GDYJ-502A
- Printer：Micro Printer, PC Connection
- Max. Test Times：9
- Stir Time：0~999s
- Wait Time：0~999s
- Oil Temperature Measurement Range：0°c to 70°c, or Better
- Power Supply：AC220V, 50Hz,60Hz(Support Customize)
- Transport Package：Plywood Case for Oil Bdv Tester
- Specification：50kg
- Trademark：GOLD
- Origin：Chongqing, China
- HS Code：9030849000
- Production Capacity：500 Pieces,Month
