• Model NO.：T-06C
• Weight：0-100Kg
• Power Source：AC220V
• Transport Package：Wooden Case
• Specification：430mm *330 *170mm
• Origin：Jiangsu, China (Mainland)

Basic Info.

Model NO. T-06C Weight 0-100Kg Power Source AC220V Transport Package Wooden Case Specification 430mm *330 *170mm Origin Jiangsu, China (Mainland)

Product Description

Test item
Composite tank packaging, soft packaging, sealing of various bottles and aluminium hoses, rapid leak test

Technical characteristics
1. Microcomputer Control, PVC Operating Panel, Humanized Design
2. Inflation pressure and holding time can be set to facilitate user observation and timing.
3. Equipped with micro-printer to print experimental results quickly
4. By changing different fixtures, it can be expanded to carry out a variety of test projects, one machine for multiple purposes.
5. Automatic Constant Pressure Gas Supplement
6. Automatic Ending Test
Testing principle
By injecting pressure gas into the sample and holding time, it can be judged whether the sample is well sealed or not. Or the sealing condition can be judged by setting high pressure outside the sample and looking at the water intake of the sample.
Technical parameters:
Measurement range 0-0.6 Mpa
Measurement accuracy (+1%)
_8mm polyurethane pipe with gas source interface
Machine size 430mm *330 *170mm (length, width and height)
