• Model NO.：SXCF
• Loading Method：Static Load
• Display：LCD
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC 110V,220V at Customized
• Oil Cylinder Position：Under
• AC Withstand Test for：0~220kv
• Max. Capacity：2000kVA
• Output Frequency：45 - 300Hz
• Waveform：Pure Sine Wave
• Frequency Adjustment Sensitivity：0.01Hz
• Transport Package：Plywood Case
• Specification：ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9030339000
• Production Capacity：100 Units

Basic Info.

Model NO. SXCF Loading Method Static Load Display LCD Control Computer Control Weight 100-500Kg Power Source AC 110V/220V at Customized Oil Cylinder Position Under AC Withstand Test for 0~220kv Max. Capacity 2000kVA Output Frequency 45 - 300Hz Waveform Pure Sine Wave Frequency Adjustment Sensitivity 0.01Hz Transport Package Plywood Case Specification ISO9001 SGS Trademark Sansion Origin Wuhan, China HS Code 9030339000 Production Capacity 100 Units

Product Description

Capacitance impulse current generator Power Testing System Long Life

System instruction Main Parameters for System

• Nominal voltage: ±200kV
• Rated stage voltage: ±100kV
• Rated energy: 10kJ
• Impulse capacitance: 0.5µF
• Number of stages: 2
• Rated stage capacitance: 1µF(each impulse capacitor 1µF at 100kV, total 2pcs)
• Impulse voltage waveform: generated when load capacitance is 300-3000pF.

T1=1.2µs±30%, T2=50µs±20%, standard lightning impulse voltage full waveform of peak voltage deviation≤3%;

Standard operation waveform 250±20%/2500±60%. These 2 Impulse voltage waveform parameters and error are accorded with national requirements of IEC standard.

• Voltage utilization factor: Standard lightning impulse voltage waveform ≥90% when load capacitance is below 1000pF, standard operation impulse voltage waveform≥80% when load capacitance is below 2000pF. Standard operation impulse voltage waveform ≥70%.
• Locking range: level voltage is within the range of 20%-100% rated voltage, positive and negative locking range no less than 25%.
• Out-of-control rate of synchronous discharge: <5%
• Min. output voltage: ≥±20% of rated voltage.
• Instability of discharge voltage: <±1.0%
• Continuous time: Above 2/3 of rated voltage, continuous working when charge and discharge once every 120s. Below 2/3 of rated voltage, continuous working when charge and discharge once every 60s.
