Customized GDJS-A PLC Control Insulation Gloves Boots Tools Test Set
HV Hipot Electric Co., Ltd.- After-sales Service：Yes
- Warranty：1 year
- control unit：automatic PLC control
- testing transformer：oil,gas,dry type
- Transport Package：Plywood Case
- Specification：5kVA. 50kV, customized
Base Info
- Model NO.：GDJS-A
- Trademark：HVHIPOT
- Origin：China
- HS Code：9030849000
- Production Capacity：600PCS,Year
Description
Basic Info.
Model NO. GDJS-A Trademark HVHIPOT Origin China HS Code 9030849000 Production Capacity 600PCS/YearProduct Description
Customized GDJS-A PLC Control Insulation Gloves Boots Tools Test SetInsulation Gloves (Boots) Test Set is special equipment for batch test of insulated gloves (boots). The test procedure is simple and personnel security is guaranteed. Parameters such as leakage current, insulation aging and frequency voltage could be obtained reliably. It can test 6pcs insulated gloves (boots) at the same time.
Features
- 7 inch color LCD screen, with PLC automation control.
- HV Voltage, HV Current(HV meter is external for monitoring), LV voltage, LV current measured at the same time, with high precision sensor and high performance collection chip.
- Automatic mode and manual mode for option.
- Display HV voltage, LV voltage, HV current (displayed by external HV meter), LV current, time and withstanding result.
- Over-voltage and over-current protection. Output voltage, HV current upper limit, LV current upper limit and timing can be set.
- Zero-starting function. Test can be proceed after the voltage is back to zero.
- Store up to 8000pcs data in 3months. It has USB port to upload data to USB disk.
- When setting voltage is arrived, it will timing automatically. After timing, voltage will be back to zero.
- When the LV current is over setting value or HV voltage is over setting value, the voltage will be cut off automatically and it will be back to zero.
- With anti-interference ability, suitable for electromagnetic environment.
- With wheels for HV unit and gloves(boots) platform, easy to move.
Technical Specifications
| Rated capacity | 5kVA, customized |
| Input voltage | AC240V±10%,50Hz±1 |
| Output voltage | 0-50kV, customized |
| Voltage accuracy | ≤1.0% (F.S) |
| Low voltage current | 0-25A |
| Leakage current | 0-20.0mA |
| Leakage current resolution | 0.1mA |
| Current accuracy | ≤1.0% (F.S) |
| Timing range | 0-999s |
| Environmental temperature | -20ºC to 50ºC |
