3-way AC Hipot Generator 200VA, 2kV
HV Hipot Electric Co., Ltd.- Type:Withstand Voltage Test Set
- Load Way:Electronic Load
- Loading Method:Dynamic Load
- Display:Digital
- Control:Manual Control
- Power Source:AC 120V
Base Info
- Model NO.:GDYD-0202
- Power Supply:AC 120V
- Frequency:60Hz
- Output voltage:0-2kV, AC
- Capacity:200VA
- Duty cycle:220hours
- HV Source:Epoxy resin
- Output control:Manual control
- Transport Package:Wooden Case
- Specification:ISO, SGS
- Trademark:HV Hipot
- Origin:Wuhan China
- HS Code:9030332000
- Production Capacity:2000PCS,Year
Description
Basic Info.
Model NO. GDYD-0202 Power Supply AC 120V Frequency 60Hz Output voltage 0-2kV, AC Capacity 200VA Duty cycle 220hours HV Source Epoxy resin Output control Manual control Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 2000PCS/YearProduct Description
Features
1. Digital display panel mounted controls & indicators with easy to read legend.
2.Monitoring secondary side voltage, secondary side current and indicator of zero, power, working start, timing.
3. Over-current protection, zero-starting protection, sound and light alarm.
4. Over-current relay supply a reactive signal to tracking tester.
5. Continuously variable output from zero to full voltage.
6. With three time relays, time range is more wider (1S-9999H).
7. Using the latest current relay, more accurate and reliable.
8. With wheels, easy to move.
Technical Specifications
Power Supply | AC 120V |
Frequency | 60Hz |
Output voltage | 0-2kV, AC |
Capacity | 200VA |
Duty cycle | 220hours |
HV Source | Epoxy resin |
Output control | Manual control |
Voltage accuracy | ≤1.5% (F.S) |
Current Accuracy | ≤1.5% (F.S) |
Timing range | 0-9999H |
Metering | Digital display, kV meter: AC 0-2kV, mA meter: AC 0-200mA |
Humidity | 85% RH |
Environmental temperature | -20ºC~50ºC |
Weight | About 75kg |
Accessories
Main unit
Power cord
HV cable
Ground cable
User's guide
Factory test report
