1.2kVA 60kV AC Dielectric Test System
HV Hipot Electric Co., Ltd.- Type:Withstand Voltage Test Set
- Load Way:Electronic Load
- Loading Method:Dynamic Load
- Display:Digital
- Control:Manual Control
- Power Source:AC 120V
Base Info
- Model NO.:GDYD-62D
- Input:AC220V,380V ± 10%
- Frequency:50Hz ± 1
- Output:0-60kV, 20mA AC RMS
- Rating:100%Rated-1minute , 50%-continuous
- Capacity:1.2kVA
- HV Source:Epoxy resin cast HT transformer(Dry type testing t
- Output control:Manual control
- Transport Package:Wooden Case
- Specification:ISO, SGS
- Trademark:HV Hipot
- Origin:Wuhan China
- HS Code:9030332000
- Production Capacity:2000PCS,Year
Description
Basic Info.
Model NO. GDYD-62D Input AC220V/380V ± 10% Frequency 50Hz ± 1 Output 0-60kV, 20mA AC RMS Rating 100%Rated-1minute , 50%-continuous Capacity 1.2kVA HV Source Epoxy resin cast HT transformer(Dry type testing t Output control Manual control Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 2000PCS/YearProduct Description
Features
1. Digital display panel mounted controls & indicators with easy to read legend.
2. Monitoring high voltage side voltage, low voltage side current and indicator of zero, power, working start,timing.
3. Over-current protection, zero-starting protection,sound and light alarm.
4. Continuously variable output from zero to full voltage.
5. Adjustable over current protection, with trip levels variable from 10 to 110%.
6. With new type time relay, time range is more wider (1S ~ 99H).
7. Using the latest current relay, more accurate and reliable.
8. Light weight, small size, easy to move.
Technical Specifications
Input | AC220V/380V ± 10% |
Frequency | 50Hz ± 1 |
Output | 0-60kV, 20mA AC RMS |
Rating | 100%Rated-1minute , 50%-continuous |
Capacity | 1.2kVA |
HT Source | Epoxy resin cast HT transformer(Dry type testing transformer) |
Output control | Manual control |
Voltage accuracy | ≤ 1.5% (F.S) |
Current Accuracy | ≤ 1.5% (F.S) |
Timing range | 0-99H |
Metering | Digital display, kV meter: 0-60kV AC, mA meter:0-20mA AC, A meter:0-7.5A AC |
Humidity | 85% RH |
Environmental temperature | -20ºC~50ºC |
Weight | Control Unit: About 18kg Dry Testing transformer: About 28kg. |
