AC Dielectric Test System 3kVA/15kVAC
HV Hipot Electric Co., Ltd.- Type:Withstand Voltage Test Set
- Load Way:Electronic Load
- Loading Method:Dynamic Load
- Display:Digital
- Control:Manual Control
- Power Source:AC220V ± 10%
Base Info
- Model NO.:GDYD-3,15
- Input:AC220V ± 10%
- Frequency:50Hz ± 1
- Output:0-15kV, 200mA AC RMS
- Rating:100%Rated-1minute , 50%-continuous
- Capacity:3kVA
- HV Source:Epoxy resin cast HV transformer
- Output control:Manual control
- Transport Package:Wooden Case
- Specification:ISO, SGS
- Trademark:HV Hipot
- Origin:Wuhan China
- HS Code:9030332000
- Production Capacity:2000PCS,Year
Description
Basic Info.
Model NO. GDYD-3/15 Input AC220V ± 10% Frequency 50Hz ± 1 Output 0-15kV, 200mA AC RMS Rating 100%Rated-1minute , 50%-continuous Capacity 3kVA HV Source Epoxy resin cast HV transformer Output control Manual control Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 2000PCS/YearProduct Description
Features
1. Digital display panel mounted controls & indicators with easy to read legend.
2. Monitoring high voltage side voltage, low voltage side current and indicator of zero, power, working start, timing.
3. Over-current protection, zero-starting protection,sound and light alarm.
4. Continuously variable output from zero to full voltage.
5. Adjustable over current protection, with trip levels variable from 10 to 110%.
6. With new type time relay, time range is more wider (1S ~ 99H).
7. Using the latest current relay, more accurate and reliable.
8. Light weight, small size, easy to move.
Technical Specifications
Input | AC220V ± 10% |
Frequency | 50Hz ± 1 |
Output | 0-15kV, 200mA AC RMS |
Rating | 100%Rated-1minute , 50%-continuous |
Capacity | 3kVA |
HV Source | Epoxy resin cast HV transformer(Dry type testing transformer) |
Voltage accuracy | ≤ 1.5% (F.S) |
Current Accuracy | ≤ 1.5% (F.S) |
Timing range | 0-99H |
Metering | Digital display, kV meter: 0-15kV AC, mA meter: 0-200mA AC, A meter: 0-15A AC |
Humidity | 85% RH |
Environmental temperature | -20ºC--50ºC |
Weight | Control unit: about 18kg Dry testing transformer: about 28kg |
