Circuit Contact Resistance Tester (200A) (GDH-200)

HV Hipot Electric Co., Ltd.
  • Type：Test and Measurement Instruments
  • Maxcapacity：DC 100A-200A Continuous Adjustment
  • Accuracy Grade：0.5
  • Load Way：Electronic Load
  • Loading Method：Dynamic Load
  • Display：Digital

Base Info

  • Model NO.：GDH-200
  • Control：Manual Control
  • Weight：20kg
  • Power Source：AC220V
  • Input Voltage：AC220V+-20%, 50Hz
  • Output Current：DC 100A-200A Continuous Adjustment
  • Testing Current：DC100A
  • Accuracy：0.5%
  • Resolution：1microhm
  • Measuring Range：DC100A: 0 ~ 1000microhm; DC200A: 0 ~ 2000microhm
  • Transport Package：Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan China
  • HS Code：9030332000
  • Production Capacity：2000PCS,Year

Description

Input voltageAC220V+-20%, 50HzOutput currentDC 100A-200A continuous adjustmentTesting CurrentDC100AAccuracy0.5%Resolution1microhmMeasuring range DC 100A: 0 ~ 1000microhm
DC 200A: 0 ~ 2000microhm

Circuit Contact Resistance Tester (200A) (GDH-200)
