• Model NO.：GD-0613A
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GD-0613A HS Code 9031809090 Production Capacity 100sets/Month

Product Description

Automatic Asphalt Fraass Breaking Point Tester for Bitumen and Bituminous Binders




Introduction:The Automatic Asphalt Fraass Breaking Point Tester is used to determine the temperature which a bitumen tends to break rather to flow when cooled and stressed as per standards GB/T 4510 and JTG E20-2011.
The  Automatic Asphalt Fraass Breaking Point Tester can do three tests at the same time in the same environment and calculate the average value. The cooling rate is controlled by computer.


Features:
The  Automatic Asphalt Fraass Breaking Point Tester is controlled by micro computer. The cooling rate is controlled automatically.
The  Automatic Asphalt Fraass Breaking Point Tester automatically timing to bend samples.The test data is shown on the colored LCD and outputted by built-in printer.


Specifications:
1. Power supply:      AC(220±10%)V, 50Hz
2. Refrigeration mode:     Low temperature circulatory bath
3. Cooling rate:     (1±0.5)ºC/min
4. Temperature measuring range:     -30ºC~25ºC
5. Temperature measuring error:     ±0.5ºC
6. Steel slice:  41mm×20mm×0.15mm
7. Test samples:   It can determine 3 samples at the same time.
8. Ambient temperature:    Room temp. ~+30ºC
9. Relative humidity:     ≤85%
10.Power consumption:    450W(breaking point tester)+ 1600W(low temperature circulatory bath)
11.Overall dimension:     500mm×400mm×570mm(breaking point tester)


Note: We can customize the breaking point tester with measuring range: -40ºC~25ºC
