Product Description

ASTM D6648 BBR Bending Beam Rheometer for Determining the Flexural Creep Stiffness of Asphalt Binder


 Introduction:
The BBR Bending Beam Rheometer is made and designed as per ASTM D6648 and T0728-2000 Bending Beam Test of JTG E20-2011 Standard Test Methods for Bitumen and Bituminous Mixtures for Highway Engineering.
The BBR Bending Beam Rheometer is suitable to determine the strain rate of bending creep of bituminous mixtures under specified temperature and loading stress in horizontal condition to evaluate the deformation performance of bituminous mixtures.


Features:
1. It adopts advanced sensor technology and micro-computer processing technology. It has functions of parameters setting, measurement calibration, automatic test control, automatic data collection and real-time clock.
2. It can collect the creep value and test temperature at the same time and looking for the stability region of bending creep. The deformation value, test temperature, curves, result and time will be shown on the LCD directly.
3. It can store 100 groups of test data. Operator can check them at any time.
4. It equips a RS232 communication port to achieve communicating with PC. Data process, store, print and display can be done by the computer. The whole procedures can be operated by the computer too.
5. It adopts temperature control combining electric heating with compressor refrigeration. The temperature control accuracy is high.


Specifications:
1. Loading capacity:(0~300)N
2. Loading measuring error: ≤±0.1N
3. Measuring range:  0mm~20mm(mid-span deflection)
4. Measuring bias:   ≤±0.01mm
5.Temperature control range:   -2ºC~60ºC
6. Temperature control bias:   ≤±0.1ºC
7. Motor power:    90W
8. Compressor power:  1kW
9. Heating power:   2kW
10. Pump power:   45W
11. Communication port:  RS232
12. Power supply:   AC(220±10%)V,50Hz
13. Total consumption power: 3.2kW
14.Outline dimension: 810mm*540mm*1300mm(L*W*H)
15.Net weight:   86kg
