Transformer Tan Delta Tester / Oil Tan Delta Tester and Power Factor Tester
Xi'an Xu&Hui Electromechanical Technology Co., Ltd.- Warranty:Warranty Certificate
- Transport Package:Wooden
Base Info
- Model NO.:XHJS1000R
- Specification:420mm× 250mm× 340mm
- Trademark:XZH TEST
- Origin:China Xi′an
- HS Code:854320100
- Production Capacity:100 Pieces ,Year
Description
Feature
1. Conditions of use -15°C-40°C RH<80%
2. Anti-interference principle
3. Power supply AC 220V±10% Allowed generator
4. High voltage output 0.5KV - 12KV every 0.1kV
Accuracy 2%
Maximum current 167mA
Capacity 2000VA
5. Self-excited power supply AC 0V∽50V/15A 50HZ, 60HZ single frequency
45HZ/55HZ 47.5HZ/52.5HZ
55HZ/65HZ 57.5HZ/62.5HZ
Automatic double frequency conversion
6. Points resolution tgδ: 0.001% Cx: 0.001pF
7. 7. Accuracy △tgδ: ± (reading *1.0%+0.040%) △C x :± (reading *1.0%+1.00PF)
8. 8. Measuring range tgδ Unlimited
C x: 15pF < Cx < 300nF
12KV Cx < 300 nF
5KV Cx < 150 nF
1KV Cx < 300 nF
CVT test Cx < 300 nF
9. 9. CVT ratio range 10-10000
CVT ratio accuracy 0.1%
CVT ratio resolution 0.01
10. 10. Dimensions (host) (mm) 350 (L) × 270 (W) × 270 (H)
Dimensions (accessory box) (mm) 350 (L) × 270 (W) × 160 (H)11. Memory size 200 groups Support U disk data storage
12. Weight (host) 22.75Kg

1. Conditions of use -15°C-40°C RH<80%
2. Anti-interference principle
3. Power supply AC 220V±10% Allowed generator
4. High voltage output 0.5KV - 12KV every 0.1kV
Accuracy 2%
Maximum current 167mA
Capacity 2000VA
5. Self-excited power supply AC 0V∽50V/15A 50HZ, 60HZ single frequency
45HZ/55HZ 47.5HZ/52.5HZ
55HZ/65HZ 57.5HZ/62.5HZ
Automatic double frequency conversion
6. Points resolution tgδ: 0.001% Cx: 0.001pF
7. 7. Accuracy △tgδ: ± (reading *1.0%+0.040%) △C x :± (reading *1.0%+1.00PF)
8. 8. Measuring range tgδ Unlimited
C x: 15pF < Cx < 300nF
12KV Cx < 300 nF
5KV Cx < 150 nF
1KV Cx < 300 nF
CVT test Cx < 300 nF
9. 9. CVT ratio range 10-10000
CVT ratio accuracy 0.1%
CVT ratio resolution 0.01
10. 10. Dimensions (host) (mm) 350 (L) × 270 (W) × 270 (H)
Dimensions (accessory box) (mm) 350 (L) × 270 (W) × 160 (H)11. Memory size 200 groups Support U disk data storage
12. Weight (host) 22.75Kg
