WE-A Series Dial Type Hydraulic Universal Testing Machine (JD-100K)
Qingdao Yadong Machinery Group Co., Ltd.- Transport Package：Wood Box
- Trademark：Judong
- Origin：China
Base Info
- Model NO.：JD-100K
- HS Code：9024101000
- Production Capacity：100sets,Month
Description
| Type | WE-100A | WE-300A | WE-600A | WE-1000A | ||
| Maximum force(kN) | 100 | 300 | 600 | 1000 | ||
| Measuring range and minimum scale (scl.) |
0-20kN 0.04kN/scl. 0-50kN 0.1kN/scl. 0-100kN 0.2kN/scl. |
0-60kN 0.2kN/scl. 0-150kN 0.5kN/scl. 0-300kN 1.5kN/scl. |
0-120kN 0.5kN/scl. 0-300kN 1kN/scl. 0-600kN 2kN/scl. |
0-200kN 0.5kN/scl. 0-500kN 1kN/scl. 0-1000kN 2kN/scl. |
||
| Accuracy of testing force | ±1% of indicated value | |||||
| Deformation zoom factor of tracing device | 2:1 or 4:1 | |||||
| Clamping diameter for round specimen (mm) | 6-22 | 10-32 | 13-40 | 13-60 | ||
| Clamping Thickness of flat specimen(mm) | 0-15 | 0-15 | 0-30 | 0-40 | ||
| Maximum clamping width of flat specimen | 40 | 70 | 70 | 120 | ||
| Testing space(mm) | tension | 550 | 550 | 550 | 700 | |
| compression | 270 | 700 | 300 | 750 | ||
| Platen size(mm) | 100 | 130 | 180 | 230×230 | ||
| Distance of bending by pass roll(mm) | 30-600 | 30-1000 | 30-1000 | 30-1000 | ||
| Piston stroke(mm) | 250 | |||||
| Power supply | 380V±10%,50Hz | |||||
| Working environment | 10~30temp., relative humidity≤80% | |||||
| Overall dimension (L×W×H)(mm) | Host machine | 850×565×2400 | 900×600×2550 | 1120×900×3010 | 1260×900×4000 | |
| Ergo meter | 1070×810×1730 | |||||
| Weight(kg) | 1440 | 2740 | 3040 | 4340 | ||
