• Model NO.：HD-E802-1
• Weight：100-500Kg
• Power Source：AC220V
• Temperature Resolution：0.1ºC
• Humidity Range：About 45%~70% R.H.
• Warranty Period：One Year
• Delivery Time：15 Days After Receive The Deposit
• Standard Specimen Size：75×150mm ,48PCS
• Transport Package：Strong Wooden Case
• Specification：ISO9001: 2008
• Trademark：Haida
• Origin：China
• HS Code：9031809090
• Production Capacity：60 Sets,Month

Basic Info.

Model NO. HD-E802-1 Weight 100-500Kg Power Source AC220V Temperature Resolution 0.1ºC Humidity Range About 45%~70% R.H. Warranty Period One Year Delivery Time 15 Days After Receive The Deposit Standard Specimen Size 75×150mm ,48PCS Transport Package Strong Wooden Case Specification ISO9001: 2008 Trademark Haida Origin China HS Code 9031809090 Production Capacity 60 Sets/Month

Product Description

UV Accelerated Aging Weathering Testing Chamber
Product Introduction:
In the QUV uv accelerated aging testing machine, the fluorescent uv lamp of the uv lamp can reproduce the effects of sunlight, and the condensation and water spraying system can reproduce the effects of rain and dew.
The temperature is controlled throughout the test cycle.

The typical test cycle is usually ultraviolet irradiation at high temperature and relative humidity at 100% dark moist condensation period;
Typical application in paint, automotive industry, plastic products, wood products, glue, etc.


UV Aging Testing Machine Satisfying Criteria :
Comply with astmg53-77 GB, GJB, MIL, ASTM, CNS, IEC, JIS, AATCC, DIN, Fed Test, BS, SAE

Application industry:
Quv accelerated weathering tester is widely used in coatings, inks, paints, resins, plastics, printing and packaging, aluminum profiles, adhesives, automobile and motorcycle industries, cosmetics, metals, electronics, electroplating, medicine and so on.

Technical Parameters:

Studio size	1140*400 *380mm(L*D*H)
Overall size	1300*500 *1460mm(L*D*H)
Center distance of the lamp	70mm
Distance of specimen from lamp surface	The distance between the specimen and the nearest parallel surface of the lamp surface is about 50mm
Wavelength range	UV-A wavelength range of 315 to 400nm
Radiation intensity	within 1W/m2/340nm
Temperature resolution	0.1ºC
Light temperature range	50ºC~70ºC / temperature tolerance is ±3ºC
Condensation temperature range	40ºC~60ºC / temperature tolerance of ±3ºC
Measuring range of blackboard thermometer	30~80ºC / tolerance is ±1ºC
Temperature control mode	PID self - tuning temperature control mode
Humidity range	about 45%~70% R.H.
Water tank requirements	water depth not more than 50mm, and with an automatic water supply controller
Standard specimen size	75×150mm 48pcs
Recommended operating environment	5~35ºC, 40%~85%R•H, 300mm away from the wall
Voltage	220V±5%, single-phase three-wire, 50Hz, 10A, required 15A leakage switch

(The table parameters for the company Standard Model parameters, we support customer customization parameters)
