• Model NO.：TPC-3V
• HS Code：90248000
• Production Capacity：100 Sets,Month

Basic Info.

Model NO. TPC-3V HS Code 90248000 Production Capacity 100 Sets/Month

Product Description

CPT - VST Dual-use Apparatus (TPC-3V)
    It is not only just the lightest CPT machine, but also vane shear test machine (i.e. VST). Its rated penetration force is 30KN (3t) and the test depth is up to 30m (in soft soil area). While doing CPT test, it could work with 10cm2 probe, also 10cm2 pore-pressure probe while doing CPTu test.
    This machine is manual operation, suitable for clay, silt, sand, etc. After over 20 years application and development, now it is improved to put up a perfect performance.
    Vane shear test ranges 0 ~130KPa, Cross Board To Board head confi guration 50 × 100 (mm) (general) or 75 × 150 (mm) 75 × 100 (mm) (special).



Main Technical Parameters
Structure type: light chain, hand-cranked on both sides, with support leveling mechanism.
Rated penetration force: 30KN (3 tons)
Max. penetration force: 33KN
Penetration stroke: 1m
Penetration speed: 0.9~1.2m/min (50-70 rpm manually)
Pulling force: slow speed is same as the penetration force, fast speed can reach about 4m/min
Rod: 1m for each, dia.28 x 5-6mm thickness, high quality alloy steel seamless pipe
Ground anchor: dia. 220~260mm, single blade anchor, 2 pcs
Cutting range of vane: 0~128KPa
Static probe: strained single or double bridge, 10cm²
Four-bladed vane: strained, vane dimension 50x100x2mm or 75x150x3mm
Chain: transmission chain  10A-1  70 joints x 2pcs
           transmission chain  12A-1  148 joints x 2pcs
Weight of the host: ≤60kg
