Lead Acid Battery Activation Equipment Battery Activator
HV Hipot Electric Co., Ltd.- Single cell voltage measurement type：2V,6V,12V
- Single cell voltage measurement range：2V: 0~3V, 6V,12V: 0~16V
- Voltage measurement accuracy：0.5%
- Working voltage：AC 220±15%
- Heat transfer：Forced air cooling
- Dimension：401mm * 176mm * 273 mm
Base Info
- Model NO.：GDKH-12
- Weight：15kg
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HVHIPOT
- Origin：Wuhan China
- Production Capacity：2000sets,Year
Description
Single cell voltage measurement type
2V/6V/12V
Single cell voltage measurement range
2V: 0~3V 6V/12V: 0~16V
Single cell voltage resolution
2V: 0.001V; 6V/12V: 0.001V
Voltage measurement accuracy
0.5%
Charge/discharge current range
2V: 1A~100A 6V: 1A~ 30A 12V: 1A~ 30A
Charge/discharge current control accuracy
1%
Battery capacity checking range
2V: 20Ah~ 1000Ah
6V: 20Ah~300Ah
12V: 20Ah~300Ah
Working voltage
AC 220±15%
Heat transfer
Forced air cooling
Working environment
Temperatures: 0ºC~40ºC humidity:20%~80RH
Storage conditions
-20ºC~+70ºC packaged storage
Display
High light LCD screen
Dimension
401mm * 176mm * 273 mm
Weight
15kg
