GDSL-BX-200 500A Primary Current Injection Test Set for HV Switch

HV Hipot Electric Co., Ltd.
  • Type：Strength Testing Machine
  • Accuracy Grade：1
  • Display：Digital
  • Control：Computer Control
  • Weight：0-100Kg
  • Power Source：AC220V

Base Info

  • Model NO.：GDSL-BX-200
  • Power Supply：AC 220V 50Hz.
  • Output Power：3kVA
  • Output Current：500A in Series, 1000A in Parallel
  • Output Voltage：6V in Series, 3V in Parallel
  • Accurancy：1%
  • Secondary Injection Current：50A
  • Test Range：0.001s-999.999s
  • Duty Cycle：5mins on, 10mins off
  • Transport Package：Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：China
  • HS Code：9030339000
  • Production Capacity：2000PCS,Year

Description

Current can be adjusted smoothly and continuously. The accuracy is 1.0%.Output current is standard sine wave, waveform distortion is less than 5%.Secondary injection current50AOutput currentRMS continuous adjustable.The action time of test object can be tested, the lock action time is also can be recorded at the same time.Test range0.001S-999.999S, resolution 1ms, error: 0.005%, range: ±2digitsDuty Cycle5mins ON, 10mins OFF.
