• Model NO.：YOT-150
• Temp. Resolution：0.01 Degree
• Ozone Control Precision：+,- 10%
• Inner Chamber Material：SUS#304 Stainless Steel
• External Chamber Material：Cold Rolled Sheet+Powder Coating
• Circulation：Sirocco Fan
• Insulaiton：PU&Fiberglass Wool
• Ozone Concentration：0~1000pphm, Adjustable
• Ozone Production Mode：Ozonator
• Sample Frame：Static and Dynamic Fixtures
• Sample Frame Speed：1 Circle,Min 360° Rotation
• Service：Customized
• Transport Package：Strong Plywood Case
• Specification：1 set
• Trademark：Yuanyao
• Origin：Guangdong, China
• HS Code：8514109000
• Production Capacity：100 Sets,Mont

RT~80ºCTemperature fluctuation±0.5ºCTemperature uniformity±1.5ºC; Empty load, 30 mins after stanlizationResolution0.01ºCOzone concentration0~1000PPHM, adjustable (Optional: 0~500ppm non-standardozone control precision±10%Ozone production modeOzonatorSample frameStatic and Dynamic fixturesSample frame speed360° rotation (1 circle/minuteMaterialSUS#304 Stainless steel for inner chamber, cold rolled sheet + powder coating for external chamberInsulationPUCirculation systemCooling fanHeating systemSUS# stainless steel high speed heaterControlling systemDigital electrinic indicator + SSR+ PIDRefrigeration systemcompressor + Fin type evaporator + air/water cooling systemOzone concentration analyzerImported ozone concentration analyzerOzone generatorSilent discharge ozone generatorOther components1. Muti-layer vacuum glass obvervation window2. Controlling status indicator lamp 3. Chamber lightSafety protection device1. Over-heat protection 2. phase sequence protection 3. overload protectionPower supplyAC 1ψ220V; 3ψ380V 60/50HzCustomization serviceNon-standard or special requirements are all welcome

Company Introduce







Exhibition




Certification



Overseas Installation, Training and Maintenance



Customers' Feedback



After-sales Service




Production Process


Except 0 to 1000PPHM Dynamic Ozone Resistance Aging Test Chamber Price, Guangdong Yuanyao Test Equipment Co., Ltd also can supply:

Precision Oven Tester, Triple Type Temp. & Humidity Chamber, Temp. & Humidity Control Host, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Walk-in environmental Test Room, Temp. Humidity &Vibration Combined Test Chamber, Aging Oven Tester, Rain/Spray Test Chamber, Burn-in test equipment, Dust Tester, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester and so on.


If you are interested in our products, please contact me soon.
