• Model NO.：GD-R2815
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GD-R2815 HS Code 9031809090 Production Capacity 100sets/Month

Product Description

ASTM D2274, ISO12205 Accelerated Method Distillate Fuel Oil Oxidation Stability Tester


Introduction:
The test method of the instrument is: loading the filtered quantitative sample into an oxidation tube, introducing oxygen at a rate of 50 ml/min, oxidizing at a certain temperature for 16 hours, and then cooling the oxidized sample to room temperature, filtering, the insoluble matter can be filtered out. The adhesive insoluble matter is washed from the oxidation tube wall and the same tube wall with a triple agent, and the triple component is evaporated to obtain an adhesive insoluble matter. The sum of the amount of insoluble matter and the amount of the adhesive insoluble matter which can be filtered out is the amount of total insoluble matter expressed by mg/100 ml. This instrument is not suitable for fuel oils containing residual oils and synthetic fuel oils whose main components are non-petroleum components.


Main Features:
1. Glass test tubes meet ASTM standards.
2. Electronic timer, digital display, with wind alarm.
3. The precision flow meter regulates the flow of gas and separate flow control.
4. Six test tubes can be made at the same time, with a dark box fan cooling.
5. Microcomputer temperature controller, digital display, accuracy ± 0.2ºC PT100 sensor.
6. Three-dimensional structure.
7. Stainless steel heater, heating bath.


Technical Parameters:
1. Applicable standards: ASTM D2274, ISO12205, SH/T0175
2. Temperature control mode: digital display PID thermostat
3. Cycle mode: magnetic pump cycle
4. Temperature control range: room temperature ~ 95ºC± 0.2ºC
5. Working unit: six tubes
6. Flow tube control: flow meter adjustment
7. Timing mode: electronic timing, automatic alarm
8. Working power supply: AC220V 50HZ
