• Model NO.：GD-H1634
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GD-H1634 HS Code 9031809090 Production Capacity 100sets/Month

Product Description

ASTM D942 Oxygen Pressure Vessel Method Lubricating Greases Oxidation Stability Tester


Introduction:
The sample is oxidized in an oxygen bomb that meets the conditions. Observe and record pressure at regular intervals. After a specified period of time, the degree of oxidation of the grease is determined by a corresponding decrease in oxygen pressure. The instrument is suitable for determining the oxidation resistance of grease in static storage in an oxygen-tight system under conditions of increased test temperature.


Main Features:
1. The entire test is controlled by computer and does not require manual operation.
2. The test process has a curve real-time display.
3. Automatically store the results at the end of the test.
4. A test bomb can be loaded into 5 sample containers.
5. Stainless steel electric heater, heating bath.
6. The instrument can automatically check for gas leaks and alarms.
7. PID program temperature control technology, digital display, accuracy ± 1 ° C PT100 sensor.
8. 64-bit PIC capture card, the sampling speed is fast, and the result is processed quickly.
9. The LCD interface uses human-machine dialogue.
10. Alloy steel dish holder with 18% chromium and 8% nickel.


Technical Parameters:
1. Applicable standards: ASTM D942, IP142, SH/T0325
2. Heating method: heating tube heating
3. Control method: automatic control
4. Temperature control mode: single chip PID thermostat
5. Machine power: 2.2KW
6. Temperature control range: normal temperature ~ 99ºC
7. Work unit: two bombs
8. Result processing: automatic calculation of single chip microcomputer
9. Pressure display: LCD display curve
10. Working power supply: AC220V / 50HZ
