GDTF Series AC Resonant Test System for Generators

HV Hipot Electric Co., Ltd.
  • Rated Output Voltage：0 ~ 50kv (Effective Value) and Below
  • Output Frequency：45 ~ 300Hz
  • Waveform: Pure Sine Wave：Thd<= 1%;
  • The Maximum Test Capacity：2000kVA and Below
  • Duty Cycle: Full Power Output：Continuous 15min Work Once
  • Quality Factor：10 ~ 40

Base Info

  • Model NO.：GDTF
  • Power Supply：220V or 380V +,-15%, 50Hz +,- 5%
  • Transport Package：Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan China
  • HS Code：9030339000
  • Production Capacity：2000PCS,Year

Description

Rated output voltage0 ~ 50kV (effective value) and below;Output frequency45 ~ 300Hz;WaveformPure sine wave, THD<= 1%;The maximum test capacity2000kVA and below;Duty cycleFull power output, continuous 15min work once;Quality factor10 ~ 40;Frequency adjustment sensitivity0.1Hz, instability of <0.05%;Power supply220V or 380V +/-15%, 50Hz +/- 5%
