ASTM D1424 ASTM D1922 ASTM D689 ISO6383 Elmendorf Tearing Tester
Pubtester Instruments Co., Ltd.- Warranty：12 Months
- Display：Digital
- Control：Computer Control
- Weight：0-100Kg
- Power Source：AC220V
- Pendulum Capacity：200 GF, 400 GF, 800 GF, 1600 GF, 3200 GF, 6400 GF
Base Info
- Model NO.：FTS-01
- Sample Holder：Pneumatic
- Pendulum Release：Pneumatic
- Gas Supply Pressure：0.6MPa (Not in Supply Scope)
- Trademark：Pubtester
- Origin：China
Description
Extended
ApplicationsHeavy Package Bags Rubber Gloves Wrapping Films
Technical Specifications
Standards
ISO 6383-1-1983, ISO 6383-2-1983, ISO 1974, GB/T16578.2-2009, GB/T 455, ASTM D1922, ASTM D1424, ASTM D689, TAPPI T414
Configuration
Standard Configuration:Instrument, One Basic Pendulum, One Augmenting Weight, One Check Weight
Optional Parts:Basic Pendulum: 200 gf, 1600 gf
Augmenting Weight: 400 gf, 800 gf, 3200 gf, 6400 gf
Check Weight: 200 gf, 400 gf, 800 gf, 1600 gf, 3200 gf, 6400 gf
Computer, Sampler
Note: 1.The gas supply port of the instrument is Φ4 mm PU Tubing;
2. Customers will need to prepare for gas supply.
ABOUT US
Established in Jinan, China, Pubtester Instruments Co., Ltd has developed into a major manufacturer and supplier of flexible packaging testing instruments in China. In the year of 2020, Pubtester launched a series of testing instruments specilized in medical device (medical dressings, syringes, catheters, gloves and aseptic packaging, etc), which meet the increasing testing demand for medical industry since 2019. Pubtester has its own packaging testing center, equipped with more than 80 sets of testing instruments, which can perform barrier, force and strength, heat sealing, hot tack, coefficient of friction, thickness, tearing, impact, heat resistance, leakage, flex durability , adhesion, color, fastness and other testing items, and provide testing services to customers. By 2021, Pubtester instruments have been exported to more than 40 countries and areas including UK, Germany, Portugal, Spain, Turkey, Greece, Ukraine, UAE, Saudi Arabia, Tunisia, Nigeria, Morocco, Kenya, Thailand, Malaysia, India, Indonesia, Vietnam, Columibia, Mexico, etc. Pubtester has a great technical team of professionals, all of whom have more than 10 years experience in packaging testing industry, which provide our customers with comprehensive technical services and solutions all the time.
Applications
Technical Specifications
| Specifications | FTS-01 |
| Pendulum Capacity | 200 gf, 400 gf, 800 gf, 1600 gf, 3200 gf, 6400 gf |
| Sample Holder | Pneumatic |
| Pendulum Release | Pneumatic |
| Gas Supply Pressure | 0.6MPa (Not in Supply Scope) |
| Port Size | Φ4 mm PU Tubing |
| Instrument Dimension | 480 mm (L) × 380 mm (W) × 560 mm (H) |
| Power Supply | AC 220V 50Hz / AC 120V 60HZ |
| Net Weight | 24.5 kg (Basic Pendulum of 200 gf) |
Standards
ISO 6383-1-1983, ISO 6383-2-1983, ISO 1974, GB/T16578.2-2009, GB/T 455, ASTM D1922, ASTM D1424, ASTM D689, TAPPI T414
Configuration
Standard Configuration:Instrument, One Basic Pendulum, One Augmenting Weight, One Check Weight
Optional Parts:Basic Pendulum: 200 gf, 1600 gf
Augmenting Weight: 400 gf, 800 gf, 3200 gf, 6400 gf
Check Weight: 200 gf, 400 gf, 800 gf, 1600 gf, 3200 gf, 6400 gf
Computer, Sampler
Note: 1.The gas supply port of the instrument is Φ4 mm PU Tubing;
2. Customers will need to prepare for gas supply.
ABOUT US
Established in Jinan, China, Pubtester Instruments Co., Ltd has developed into a major manufacturer and supplier of flexible packaging testing instruments in China. In the year of 2020, Pubtester launched a series of testing instruments specilized in medical device (medical dressings, syringes, catheters, gloves and aseptic packaging, etc), which meet the increasing testing demand for medical industry since 2019. Pubtester has its own packaging testing center, equipped with more than 80 sets of testing instruments, which can perform barrier, force and strength, heat sealing, hot tack, coefficient of friction, thickness, tearing, impact, heat resistance, leakage, flex durability , adhesion, color, fastness and other testing items, and provide testing services to customers. By 2021, Pubtester instruments have been exported to more than 40 countries and areas including UK, Germany, Portugal, Spain, Turkey, Greece, Ukraine, UAE, Saudi Arabia, Tunisia, Nigeria, Morocco, Kenya, Thailand, Malaysia, India, Indonesia, Vietnam, Columibia, Mexico, etc. Pubtester has a great technical team of professionals, all of whom have more than 10 years experience in packaging testing industry, which provide our customers with comprehensive technical services and solutions all the time.
