Double Samples Automatic Bitumen Softening Point Tester Asphalt Instruments Gd-2806g

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Control：Computer Control
  • Weight：0-100Kg
  • Power Source：AC220V
  • Oil Cylinder Position：Under
  • Transport Package：Wooden Case
  • Specification：25  mPa· s~1×

Base Info

  • Model NO.：GD-2806G
  • Trademark：GOLD
  • Origin：China
  • Production Capacity：200units,Month

Description

1. Power supply:  AC 220V (-5%~+10%), 50 Hz;2. Measurement range:

32 ºC~160 ºC.

(1) Heating medium: distilled water(softening point under 80 ºC)

(2) Heating medium: glycerin (softening point over 80 ºC)

3. Temperature resolution:  0.01 ºC4. Cubage of beaker:  1000 ml5. Stirrer:  the stirring speed can be adjusted continuously.6. Heating rate:  it will be adjusted to 5.0±0.5 ºC/ min automatically after three minutes7. Heating power:  600 W8. Test result:  LCD screen shows results and printer to print.9. Computer communication interface:  RS232C communication interface10. Ambient temperature:

 The temperature should be lower than 35 ºC and keep stable.

There should not have any air draft.

11. Relative humidity:  ≤85%12. Maximum power consumption:  700 W13. Dimension:  400mm*300mm*490mm (Length * width * height)

Workshop

Chongqing Gold Mechanical&Electrical Equipment Co.,Ltd is a professional manufacturer of Petroleum Products test kits and

electrical testing equipment in China.Our products are sold to most countries in the world and they are highly popular because our good
quality and after-sale service.

At present, there are more than 150 employees, of whom more than 70% are technical personnel with college degree or above.

With strong technical force and strong development, new products have been launched continuously.

Double Samples Automatic Bitumen Softening Point Tester Asphalt Instruments Gd-2806g

Gold Equipment Service:

If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days.

We can offer operation video and English operation muanual. We can provide video-con.

Onsite Service:

1.Device installation; 2.Equipment Operation Test Technology training;3.Equipment Calibration;4.Daily maintenance and maintenance of equipment

Free technical training for visiting factories

24-hour Online contact

Free software upgrades

Free information:steel tensile test

1.Product Instruction;2.Product operation instruction/video;3.Experiment Test (test application, test report)

Device Problem Handling:

1. Social media 24 hours online communication;2. Mail Seamless Docking;3. Video Conferencing;4. Artificial free door-to-door service

Double Samples Automatic Bitumen Softening Point Tester Asphalt Instruments Gd-2806g


Exhibition

We have developed sales channels in many countries such as UAE, Saudi Arabia, Iran, Malaysia, Thailand, Pakistan, India, Germany, Belgium, USA, Mexico, Kenya,

Nigeria, South Africa and other countries worldwide. And we have gained strong advantage and high reputation in international market.

After several years' development, our products have become high intelligent and wide coverage.
And our company has become one of the leadingmanufacturer of petroleum testing instrument and electrical testing instrument.

Double Samples Automatic Bitumen Softening Point Tester Asphalt Instruments Gd-2806g
