Portable Manual Pensky-Martens Closed Cup Flash Point Tester Price Astmd 93

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Max Diameter of Workpiece：600mm
  • Mass Scope of Workpiece：<900kg
  • Type：Asphalt Wheel Tracking Tester
  • Maxcapacity：<1000KN
  • Accuracy Grade：0.5
  • Load Way：Electronic Load

Base Info

  • Model NO.：GD-261
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Manual Control
  • Weight：0-100Kg
  • Power Source：AC220V
  • Oil Cylinder Position：Top
  • Transport Package：Wooden Case
  • Specification：1320mm*750mm*1400mm
  • Trademark：GOLD
  • Origin：China
  • Production Capacity：200unit,Month

Description

1. Power supply:AC (220±10%)V, 50Hz.2. Heating device:The heating power is continuously adjustable from 0 W to 600W3. Heating rate:(1~12)ºC/min;Controllable and adjustable.4. Stirring rate: Procedure A: (90~120)RPM, Procedure B: (250±10)RPM5. Oil cup:(1) Inner diameter: 50.7mm~50.8mm.

(2) Depth: 55.7mm~56.0mm

(3) The scribed line depth of capacity of testing oil: 33.9mm~34.3mm.

(4) Capacity of testing oil:about 70ml

6. Igniting device:

(1) Igniting source: gas(or other civilian fuels,the same below)

(2) Electric ignition. Gas flame diameter:3.2mm~4.8mm

7. Thermometers:Mercury-in-glass thermometer.Specifications are as below:

 (1)Scale -5ºC~110ºC, division 0.5ºC.

 (2)Scale 20ºC~150ºC, division 1ºC.

 (3)Scale 90ºC~370ºC,division 2ºC.

8. Ambient temperature:≤ 35ºC9. Relative humidity:≤ 85%10.Maximum power consumption:650W



Workshop

Chongqing Gold Mechanical&Electrical Equipment Co.,Ltd is a professional manufacturer
of Petroleum Products test kits and electrical testing equipment in China.Our products
are sold to most countries in the world and they are highly popular because our good
quality and after-sale service.
At present, there are more than 150 employees, of whom more than 70% are technical personnel with college degree
or above.With strong technical force and strong development, new products have been launched continuously.

Portable Manual Pensky-Martens Closed Cup Flash Point Tester Price Astmd 93


Gold Equipment Service:

If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days.

We can offer operation video and English operation muanual. We can provide video-con.

Onsite Service:

1.Device installation; 2.Equipment Operation Test Technology training;3.Equipment Calibration;4.Daily maintenance and maintenance of equipment

Free technical training for visiting factories

24-hour Online contact

Free software upgrades

Free information:steel tensile test

1.Product Instruction;2.Product operation instruction/video;3.Experiment Test (test application, test report)

Device Problem Handling:

1. Social media 24 hours online communication;2. Mail Seamless Docking;3. Video Conferencing;4. Artificial free door-to-door service

Portable Manual Pensky-Martens Closed Cup Flash Point Tester Price Astmd 93

Exhibition



We have developed sales channels in many countries such as UAE, Saudi Arabia, Iran, Malaysia, Thailand, Pakistan, India, Germany, Belgium, USA, Mexico, Kenya,

Nigeria, South Africa and other countries worldwide. And we have gained strong advantage and high reputation in international market.

After several years' development, our products have become high intelligent and wide coverage.
And our company has become one of the leading manufacturer of petroleum testing instrument and electrical testing instrument.

Portable Manual Pensky-Martens Closed Cup Flash Point Tester Price Astmd 93
Packing

Goods are packed in veneer case, which is firm and safe for oversea shipment.
Portable Manual Pensky-Martens Closed Cup Flash Point Tester Price Astmd 93
