Htlh-V Sf6 Gas Reclaimer
Wuhan UHV Power Technology Co., Ltd.- Transport Package：Wooden Case or Carton
- Specification：see details
- Trademark：HV TEST
- Origin：China
Base Info
- Model NO.：SF6 Gas Reclaimer
- Production Capacity：200 Sets Per Month
Description
Index name and unitSF6 GAS RECLAIMER 1 Power AC V 400(three line five, phase sequence automatic conversion) 2 Rated maximum gas storage pressure (20 C) MPa ≤4 3 Ultimate vacuum Pa ≤10 4 Device vacuum degree Pa In the 133 Pa pressure to maintain 24h, the vacuum value increased by 400 Pa 5 SF6 compressor France Manewrop 6 Compressor pumping rate m3/h 7m³/h 7 Vacuum pump 2X-4 8 Vacuum pumping speed m3/h 15 9 Adaptation inlet pressure recovery beginning(20ºC) MPa 0~1.0 10 Electrical Equipment Recycling final pressure(20ºC) MPa ≤50 Kpa 11 After recovering oil gas control μg/g Domestic oil <10 12 Means annual leakage rate % <1 13 Means continuous trouble-free operation time h ≥1000 14 Cumulative operation time between failures h ≥5000 15 Noise level dB(A) Machine≤75 16 Theoretical capacity accumulator KG 50 17 Liquefaction compressor refrigeration Donper 18 Freezing tank L 50 19 Recycle gas moisture (PPM / V) after PPM/V 60 20 After the recovery of gas oil (PPM / V) PPM/V 10 21 Drying filtering Vacuum heating activated regeneration 22 Inflatable initial pressure (pa) pa ≤133 23 Inflatable final pressure (mpa) mpa 0.8 24 Inflatable rate (m³ / h) m³/h ≥5 25 Gasification Information Electric heating automatic temperature control 26 Vehicle type Hand push type 27 Dimensions cm 1450×810×1200 28 Total Weight kg 545 29 cooling method Air cooling 30 filtering system Using the United States HASON technology, three filter - can be more high removal of SF6 gas in the recovery of water, oil, particulate impurities and dust, to ensure that the recycling of SF6 gas recycling
Common problem
1. Is your company a sales company or a manufacturer?
Wuhan Huatian Electric Power Automation CO., LTD.is an industrial and trade enterprise, with its own factory, self-produced and self-sold. We were founded in 2004 and have fifteen years of production experience. Our company has reliable production lines, test rooms and R&D centers.
2. Whether the goods are in stock, whether they can be customized, and how long the delivery time is.
After the goods have been ordered, we can be made to order according to the special requirements of customers by using the latest technology. The delivery time is usually within 10 working days if there are no accidents.
3. Is the quality guaranteed?
In order to ensure quality, we use imported components in large quantities. After three times of quality inspection, the goods can be sent out, and the export is uniformly packed in non-fumigation wooden boxes.
4. What are the after-sales terms?
We offer free consulting service, one year warranty, and adopt various methods such as email communication, video calls, technology door-to-door, aiming to solve any after-sales problems in a timely manner.
5. What are the cooperative countries or regions?
Products have been successfully exported to the United States, Brazil, Australia, Russia, the Netherlands, Indonesia, Bangladesh, Iran, India, Saudi Arabia, Mongolia, Japan and other countries and regions. In the United States, India, Vietnam and other regions have cooperative distributors, can provide thoughtful services.
Contact us
Address: T4, No. 1, High-tech 2 Road,East Lake High-tech Development Zone,Wuhan
Zip code: 430074
Tel:(+86)-27-8745 7960 / (+86)027-87993136 / 13808601259
Fax: (+86)-27-8799 3136
| model | SF6 GAS RECLAIMER |
| Vacuum pumping speed (m3 / h) | 15 |
| Ultimate vacuum (Pa) | 10 |
| Vacuum pump | Domestic bipolar vacuum pump |
| SF6recovery compressor (m3 / h) | 7 |
| pressure(MPa) | 2.5 |
| Compressor manufacturers | France Manewrop |
| Filter particles (micron) | 0.02 |
| Oil (PPM) | Efficient |
| Acid value (PH) | 0.1 |
| Hydrolyzable fluoride (PPM) | 0.2 |
| Toxicity | / |
| Water (PPM) | ≤60 |
| SF6 Purity | ≥99.9% |
| SF6 tank | 50L |
| SF6 tank material | carbon steel |
| Cooling System | High quality and high efficiency compressor |
| filter | Original USA |
| Dryer | Original USA |
| Gauge | pointer |
| valve | Unique technology (built butterfly sealed to ensure multiple switch does not leak) |
