100kV/30kVA AC Hipot Test Equipment (gas transformer)

HV Hipot Electric Co., Ltd.
  • Type：Withstand Voltage Test Set
  • Maxcapacity：0-300kv
  • Accuracy Grade：1.5%
  • Load Way：Electronic Load
  • Loading Method：Dynamic Load
  • Display：Digital

Base Info

  • Model NO.：GDYD-M
  • Control：Manual Control
  • Weight：100-500Kg
  • Power Source：AC220V
  • Power Supply：AC220V±10%, 50Hz
  • Output Voltage：0-100kV, AC
  • Capacity：30kVA
  • HV Source：SF6 gas filled transformer (Gas type testing trans
  • Output control：Manual control
  • Voltage accuracy：≤1.5% (F.S)
  • Current Accuracy：≤1.5% (F.S)
  • Transport Package：Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan China
  • HS Code：9030332000
  • Production Capacity：2000PCS,Year

Description

Basic Info.

Model NO. GDYD-M Control Manual Control Weight 100-500Kg Power Source AC220V Power Supply AC220V±10%, 50Hz Output Voltage 0-100kV, AC Capacity 30kVA HV Source SF6 gas filled transformer (Gas type testing trans Output control Manual control Voltage accuracy ≤1.5% (F.S) Current Accuracy ≤1.5% (F.S) Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030332000 Production Capacity 2000PCS/Year

Product Description

100kV/30kVA AC Hipot Test Equipment (gas transformer)

Features

Digital display panel mounted controls & indicators with easy to read legend.
Monitoring high voltage side voltage, low voltage side current and indicator of zero, power, working start, timing.
Over-current protection, zero-starting protection, sound and light alarm.
Continuously variable output from zero to full voltage.
With new type time relay, time range is more wider (1S ~ 99H).
Using the latest current relay, more accurate and reliable.
All equipment equipped with wheels, easy to move.

Technical Parameter

Power SupplyAC 380V±10%; 50Hz±1Hz;(Other frequency or voltage can be customized.)
Output voltage0-100kV,AC
Capacity30kVA
HV SourceSF6 gas filled transformer (Gas type testing transformer)
Output controlManual control
Voltage accuracy≤1.5% (F.S)
Current Accuracy≤1.5% (F.S)
Timing range0-99H
MeteringDigital display, kV meter: 0-100kV, mA meter:0-300mA
Humidity85% RH
Environmental temperature-20ºC~50ºC
Weight: Control UnitAbout 120kg
20kVA/100kV gas testing transformerabout 150kg

Accessories

Control Unit1 piece
testing transformer(HV unit)1 piece
Power cord1 piece
Metering cable1 piece
Output cable1 piece
HV cable1 piece
Ground cable1 piece
User's guide1 piece
Factory test report1 piece
