IEC 61000-4-2 EMC Test High Voltage 20kv Electrostatic Discharge ESD Generator / Simulator (ESD 20K)

Shanghai Shinegil Trading Co., Ltd.
  • Max Diameter of Workpiece：<500mm
  • Mass Scope of Workpiece：<900kg
  • Type：ESD Immunity Test
  • Maxcapacity：Non
  • Accuracy Grade：Non
  • Load Way：Electronic Load

Base Info

  • Model NO.：ESD 20K
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control
  • Weight：0-100Kg
  • Power Source：AC220V
  • Oil Cylinder Position：Non
  • Product Name：ESD Generator , Simulator
  • Application：for Electrostatic Discharge Immunity Test
  • Standard：IEC , En 61000-4-2
  • Warranty：1 Year
  • Power Supply：Custom
  • OEM Service：Available
  • Certificate：ISO9001
  • Discharge Mode：Contact and Air Discharge
  • Discharge Circuits：150PF 330ohm
  • Discharge Trigger：Manual, Automatic and Remote
  • Transport Package：Wooden Case, Pallet
  • Specification：weight: 10kg
  • Production Capacity：2000sets,Year

Description

ModelESD 20KStandardIEC61000-4-2,GB/T 17626.2Operation7" Touch Panel DisplayOutput voltage0.2~±20kVPolarityPositive/ negative/ alternatingEnergy storage capacity150pFDischarge resistor330ΩDischarge current rise time0.6~1nsThe first peak current (±15%)7.5A at 2kV/ 15.0A at 4kV/ 22.5A at 6kV/ 30.0A at 8kV Current at 30ns (±30%)4.0A at 2kV/ 8.0A at 4kV/ 12.0A at 6kV/ 16.0A at 8kVCurrent at 60ns (±30%)2.0A at 2kV/ 4.0A at 4kV/ 6.0A at 6kV/ 8.0A at 8kVHolding Time (air discharge)≥5sDischarge ModesContact Discharge & Air DischargeOperating ModesSingle discharge & repetitive dischargesDischarge TriggerManual, automatic or remoteWorking ModeIEC level mode/ user mode/ program mode/ voltage rising patternsDischarge Interval0.05~9.99sDischarge Count1~9999Power SupplyAC220V ± 10%,50/60Hz (custom specific on demand)Ambient Temperature15ºC~35ºC
