• Model NO.：HJ-80
• Oil Cylinder Position：No
• Workpiece Quality：5 Kg
• Distance Between Two Supports：250~1050mm
• Support Shaft Diameter Range：6~12mm
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-80 Oil Cylinder Position No Workpiece Quality 5 Kg Distance Between Two Supports 250~1050mm Support Shaft Diameter Range 6~12mm Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

This machine is mainly used for balance correction of cross-flow fan blades of air conditioners and other similar rotating workpieces. The belt drive is adopted to ensure the balance quality and precision of the workpiece, and it has the characteristics of convenient loading and unloading, quick start and high work efficiency. The measuring system adopts a new type of computer to measure the electric control box. The speed, magnitude and phase are displayed intuitively. There are 6 types of rotors to choose from. The electromechanical transducer adopts piezoelectric sensor, which has large output, small size and stable performance.


Workpiece quality	5 Kg
Workpiece diameter	≤300mm
Balance speed	300-1500r/min (optional frequency converter can realize stepless frequency conversion speed regulation)
distance between two supports	250~1050mm
Support shaft diameter range	6~12mm
Minimum reachable residual inequality emar	≤0.5g.mm/kg
Unbalance reduction rate URR	≥90%
Machine load	≤1KVA
Power supply	220V

Product function description
1. The LCD industrial computer displays the speed, magnitude, phase, fixture compensation, plus/minus adjustment switching mode, and accuracy level.
2. The system has its own self-checking function, which can accurately carry out fault self-checking
3. It can store the size parameters of 20 kinds of workpieces, which is convenient for the conversion of workpieces with variable specifications and avoids complicated input work.
4. The functions of calibration and fixture eccentricity compensation support users to randomly check the accuracy of detection and adjustment
5. Users can choose the method of adding weight and removing weight according to their needs
6. Make standard rotors for electrical appliances, which is more convenient for users to check and adjust the equipment by themselves
4. Product Features
1. Operate in the form of menu, which can realize man-machine dialogue
2. Complete industrial computer design, safe to use, suitable for normal use in harsh production site environments, and good stability
3. The circuits of amplification, filtering, operation, etc. have been modularized, which is convenient for maintenance
4. The complete digital circuit operation mode has high precision, and the use of program control brings feasible space for future upgrades of the equipment
5. The unbalanced amount is directly displayed in "g" or "mg"
6. The electromechanical transducer adopts piezoelectric ceramic sensor, which is characterized by small size, large output and high sensitivity
