• Test Angle：45°
• Load：Adjustable, 500g, 250g
• Test Platform Moving Speed：5mm,Sec, Adjustable
• Travel Distance：40mm
• Platform：About 12*17cm, Can Fix Samples
• Accessories：Standard Pencils 6b~6h Each, a Total of 13 Pieces,
• Transport Package：Standard Export Case Packing
• Trademark：Minder
• Origin：China
• Production Capacity：20sets,Month

Basic Info.

Test Angle 45° Load Adjustable, 500g, 250g Test Platform Moving Speed 5mm/Sec, Adjustable Travel Distance 40mm Platform About 12*17cm, Can Fix Samples Accessories Standard Pencils 6b~6h Each, a Total of 13 Pieces, Transport Package Standard Export Case Packing Trademark Minder Origin China Production Capacity 20sets/Month

Product Description

Product description
Electric pencil hardness tester is specially used for spray hardness test of various finished products. Such as: mobile phone shell, MP3/MP4 shell, laptop shell and other kinds of home appliances digital product shell spraying hardness test. The machine is electric(semi-automatic) control, the machine moves through a stepper motor to achieve front and rear movement, low noise and stability! The test itinerary is adjustable according to specific requirements.
Pencil hardness tester test instructions: scratch the surface of the coating with a hardness pencil to test the surface hardness of the coating layer. The hardness pencil is fixed at an angle of 45°, so that the front end pen center contacts the surface of the coating layer, and appropriate load is applied. Move the test platform at a certain speed( JIS specification 0.5mm/s) to move the surface of the coating layer through the pen center, and the coating layer will not cause damage( scratch) to the softest pencil grade. It can be regarded as the hardness of coating layer.
Technical parameters

Name	Desktop electric pencil hardness tester
model	5608
Test angle	45°
Load	Adjustable, 500g, 250g
Test platform moving speed	5mm/sec, adjustable
Travel distance	40mm
Platform	About 12*17cm, can fix samples
Power supply	220V / 50Hz
Accessories	Standard pencils 6B~6H each, a total of 13 pieces, a set of weights

If you need more further details about our machines,  please feel free to contact us .
