• Model NO.：GDJ-T
• Origin：China
• HS Code：9031809090
• Production Capacity：100sets,Month

Basic Info.

Model NO. GDJ-T Origin China HS Code 9031809090 Production Capacity 100sets/Month

Product Description

Automatic Liquid Particle Counter for Detecting Particles in Oil


Introduction:

• GDJ-T Automatic Oil Partical Counter adopts the shading principle which specified by the International Hydraulic Standards Committee.
• Built-in four commonly used standards GJB 420B, NAS1638, ISO4406, ГOCT17216-71.
• It adopts the advanced high pressure syringe pump injection system, support custom volume.
• The particle counter is specifically designed for detecting the contaminated particles in oil, which is according to the standard GB/T 18854-2002 (ISO11171-1999) and other national and international standards.
• The Automatic Oil Partical Counter is suitable for hydraulic oil, lubricating oil, power plant fuel oil, insulating oil and turbine oil.
• The device is fully compliant with the corresponding national military standard and international standards.
• The Automatic Oil Partical Counter is developed by the principle of light blockage method(shading method) which can provide fast, accurate, reliable and repeatable test results. And it can provide the complete pollution monitoring analysis report.
• The large-screen touch human-machine interface is easy to operate.


Features:

• It adopts the counting principle of light blockage method(shading method) which specified by the International Hydraulic Standards Committee.
• It adopts the advanced injection pump combined with positive pressure injection system, so that the injection speed is stable and the sampling accuracy is high.
• Self-set sampling volume for easy detection.
• Built-in four commonly used standards GJB-420B, NAS1638, ISO4406 and ГOCT17216-71.
• Built-in two calibration curves, compatible with all domestic and international standards.
• Support for custom standard testing.
• Full-featured automatic operation without external computer or printer.
• Using laser diodes as a light source for superior performance and long life.
• It adopts the bottle sampling method, wide pressure range, can test samples of different viscosities.
• With data storage for easy viewing.
• Simple elegant design, touch screen for easy operation.

Application:

• Laboratory oil analysis
• Acceptance of hydraulic equipment and routine maintenance
• System cleaning verification
• Cleaning verification of parts
• Wear test of hydraulic components

Specifications:


Light source	Semiconductor laser
Particle size	1um~500um
Channel number	8channel, size can be set free(in the range of selected curve)
Sampling volume	0.2-1000ml
Sampling speed	5mL/min~80mL/min
Resolution	<10%
Limit coincidence error	10,000 grain/mL
Calibration	according to GB18854
Relative humidity	5ml/min-80ml/min
Ambient Temperature	5ºC-40ºC
Fluid Specifications	Pressure: 0.8Mpa; Vacuum: 0.1Mpa
Electrical Connection	Communication: RS232 port ;     Power Supply : AC220V±10%; 50Hz; ≤200W
Main Assembly	the instrument and a pump
